A2J PELVI.LOC PL-2DA User manual

Assembly!Instructions!and!Manual!

PL62DA!!6M,!6L

For"the"safe"use"of"this"product,"read"and"observe"these"assembly"instructions"and"the"manual"before"

the"first"use."

Intended!use"

The"PELVI.LOC®""PL=2DA"is"intended"for"people"with"restricted"mobility,"especially"for"thigh"positioning"

within"the"wheelchair"and"active=wheelchair"and"prevents"from"sliding"forward."

Intended!Patient!Group:!

="Adolescents"and"adults"

="Sex:"female"and"male""

Receipt!Control!

Completely"unpack"the"product"and"check"the"delivery"for"completeness"and"transport"damages."Should"

you"–"against"expectation"–"find"a"defect"in"the"delivered"product"then:"

1. Immediately"lodge"a"complaint"with"the"freight"carrier

2. Have"the"damage/defect"recorded

3. Notify"us"or"your"retailer"immediately

Scope!of!Delivery!

1) 1"x"PELVI.LOC®""PL=2DA"""=M,"=L,"""pre=assembled

2) 2"x"Cable"ties"7.8"mm

3) 1"x"Information"for"online"download"of"the"manual

Combination!of!medical!devices!

Suitable"for"medical"devices"which"are"intended"for"the"use"of"a"thigh"positioning"belt"

Assembly!

"Assembly"should"be"carried"out"by"a"person"with"specialist"knowledge."

1." Place"the"paddings"(a)"on"thigh"area."–"With"the"ratchet"(b)"facing"upwards."

!" Afterwards,"the"logo"on"the"padding"should"be"readable"from"the"front"side!"

2." Set"the"spacing"of"the"paddings"via"the"ratchet"(b)"by"operating"the"buckles"(e)."

!" The"hinge"of"the"ratchet"should"be"centred"between"the"paddings."

!" Pull"out"the"ratchet"not"further"than"to"the"point,"where"two"teeth"are"still"free"behind"each"catch"

of"the"buckle"(c)."

!" The"Velcro"(g)"can"be"released"for"adjustments"and"the"padding"can"be"opened"(only"applies"to"

straps"with"covered"buckles)""

3." After"that,"attach"the"hole"strap/webbing"(f)"to"the"frame"tube"of"the"wheelchair."""

4." Tighten"the"ratchet"(b)"on"both"sides"equally"to"a"degree"that"still"allows"enough"space"for"a"flat"

hand"between"the"thigh"and"the"paddings."

5." Both"ends"of"the"ratchet"can"be"cut"to"length"in"a"semicircle,"if"required."Deburr"the"ends"of"the"

cut"ratchet,"if"necessary."–Danger"of"injury!"

6." Check"the"firm"fit"and"locking"on"both"sides"of"the"ratchet!"

Manual!

Safety!Notes!

In"spite"of"their"stable"construction,"components"like"the"hole"straps,"webbings,"ratchets"and"paddings"

are" subject" to" wear" and" tear." It" is" therefore" recommended" to" perform" a" thorough" inspection" of" the"

PELVI.LOC®""every"3"Months."It"is"thereby"important"to"make"sure"the"rivet"and"screw"connections"(d)"

are"firmly"secure!"(if"applicable)""

!" Before"using"the"product,"ensure"that"it"is"in"a"serviceable"condition"and"that"it"fits"correctly."–

Danger"of"accidents!"

!" Do"not"patch"up"and/or"glue"up"and"reuse"damaged"components"such"as"hole"staps/webbings"

(f),"ratchet"(b)"or"padding"(a)."–"Danger"of"accidents!"

!" Do"not"sit"on"the"paddings"–"danger"of"bruising,"especially"by"the"catches"of"the"buckles"(c)!"

!" Do"not"lift"the"wheelchair"by"the"PELVI.LOC®."Danger"of"accidents!"

!"Be"careful"that"your"hands"do"not"get"caught"between"the"webbing"and"the"frame"or"seat"tube."

Danger"of"crushing!"

Restrictions!on!use!/!undesirable!side!effects!

!" Do"not"use"the"PELVI.LOC®"if"there"are"any"bruises,"wounds"or"other"not"well=healed"injuries"

in"the"area"where"the"paddings"will"be."–"Danger"of"injury!"

!" Do"not"use"the"PELVI.LOC®"in"case"of"osteoporosis,"brittle"bone"disease"or"severe"circulatory"

disorders."–"Danger"of"injury!"

!" After"cleaning,"ensure"the"correct"functioning"of"the"PELVI.LOC®"!"

!"A"damaged"PELVI.LOC®""must"be"replaced"immediately."–"Danger"of"accidents!"

Attention:!

!"The" PELVI.LOC®" is" not" part" of" the" restraint" system" for" the" wheelchair" and/or" user" during"

transport"in"a"vehicle"for"the"transport"of"disabled"persons."

!" Neither"the"manufacturer" nor"the"distributor"will"be"liable,"in"the"sense"of"product"liability,"for"

damages"or"risks"caused"by"unattended"children"with"regard"to"the"product!"

Handling!!

1." To"use"the"PELVI.LOC®""place"the"paddings"(a)"on"the"thighs""

Caution:"Make"sure"that"there"are"no"items"under"the"padding!"This"will"prevent"painful"bruises."

2."Important:!Do"not"put"it"on"the"hip"or"the"iliac"spine."

3." After"that,"guide"the"ratchet"(b)"through"the"corresponding"catch"of"the"buckle."For"that,"operate"

the"corresponding"pressure"buckle"(e)."

4." Then,"tighten"the"ratchet"(b)"to"a"degree"that"still"allows"enough"space"for"a"flat"hand"between"

the"thigh"and"the"padding."

5." Make"sure"that"the"catches"of"the"buckles"(c)"engage"with"the"teeth"of"the"ratchet!""

!" Check"the"tension!"

In"case"of"an"accidental"loosening"the"PELVI.LOC®*"positioning"system"can"be"tightened"again."

To!open!the!PELVI.LOC®"!operate"the"catch"of"the"buckle"(c)"and"pull"out"the"ratchet"(b)."

!" Make"sure"that"the"paddings"do"not"get"caught"between"the"stokes"of"the"driving"wheel!"

Cleaning!and!Disinfection!

!" Machine"washable"up"to"40"degrees."

!" Thermochemical"disinfection"possible"by"adding"ELTRA"40"when"washing""

!" No"spinning"

!" Not"dryer=proof"

Maintenance!

Inspect"the"PELVI.LOC®""for"damages"and"check"the"functioning"on"a"regular"basis."

Repair!

Immediately"replace"defective"PELVI.LOC®""systems."

Disposal!

•" The"packaging"is"recyclable."

•" The"metal"parts"can"be"disposed"of"through"scrap"metal"recycling. "

•" Plastic"parts"are"suitable"for"plastic"recycling.""

•" The"disposal"must"be"made"according"to"national"statutory"provisions."

•" Please"inquire"with"your"city"or"municipal"administration"about"local"disposal"services."

Technical!Data!

Seat!width!(cm)!

30"="40"

36"="46"

Padding!size!(cm)!

23"x"12"

28"x"14"

Weight!(g)!

280"

Predetermined!breaking!

point!(at!approx.!kg)!

80"

Product"is"

latex=free"

Ratchet!size!M!6!L!

2,4"x"0,2"x"17,0"cm"

Warranty!

We"provide"warranty"for"this"product"in"accordance"with"the"legal"provisions."This"warranty"includes"

material"and"processing"defects."This"does"not"include"wear"parts"and"components/assemblies"that"are"

subject"to"intended"wear"and"tear"as"well"as"damages"that"are"the"result"of"excessive"strain,"unintended"

use,"forcible"damage"or"unauthorised"modification/repair."If"you"wish"to"make"a"warranty"claim,"please"

inquire" with" the" retailer" you" purchased" the" product" from." For" product" liability" reasons," repairs" and"

maintenance"work"must"only"be"conducted"by"authorised"speciality"retailers,"using"original"spare"parts."

Manufacturer:! !

A2J"GmbH"

Am"Fuchsberg"13"

D=87452"Altusried"

Fon:"+49"(08373)"987269"

Fax:"+49"(08373)"987276"

eMail:"info@a2j=intl.com"

Internet:"www.a2j=intl.com"

This" product" complies" with" the" essential"

requirements" of" the" EC" Directive" 93/42/EEC"

concerning"medical"devices"

As"of""01.03.2019"

Subject"to"technical"modifications"
