1 Introduction

1.1 About the appliance This manual describes how to install, service and use the ADM appliance. The

ADM appliance is a gas-fired open boiler without fan. ADM appliances are

equipped with a flue gas backflow safeguard.

The ADM is an appliance of type B11BS.

The information in this manual applies to types: ADM 40, ADM 50, ADM 60,

ADM 80, ADM 90, ADM 115 and ADM 135.

The appliance has been manufactured and equipped in accordance with the

European standard for gas-fired storage water heaters for the production of

domestic hot water (EN 89). The appliances are therefore compliant with the

European Directive for Gas Appliances, and and are entitled to bear the CE mark.

Warning

Read this manual carefully before starting up the water heater. Failure to

read the manual and to follow the printed instructions may lead to personal

injury and damage to the appliance.

1.2 What to do if you

smell gas

Warning

If there is a gas smell:

No naked flames! No smoking!

Avoid causing sparks! Do not use any electrical equipment or switch, i.e. no

telephones, plugs or bells!

Open windows and doors!

Shut off the mains gas supply valve!

Warn occupants and leave the building!

After leaving the building, alert the gas distribution company or your installation

engineer.

1.3 Regulations As the (end) user, installation engineer or service and maintenance engineer,

you must ensure that the entire installation complies, as a minimum, with the

official local:

• building regulations;

• energy supplier's directives for existing gas installations;

• directives and technical guidelines for natural gas installations;

• safety requirements for low-voltage installations;

• regulations governing the supply of drinking water;

• regulations governing ventilation in buildings;

• regulations governing the supply of air for combustion;

• regulations governing the discharge of products of combustion;

• requirements for installations that consume gas;

• regulations governing indoor waste water disposal;

• regulations imposed by fire brigade, power companies and municipality.

Furthermore, the installation must comply with the manufacturer's instructions.

0063

Introduction

8Instruction manual ADM

1gis

Note

Later amendments and/or additions to all regulations, requirements and

guidelines published on or prior to the moment of installing, will apply to the

installation.

1.4 Target groups The three target groups for this manual are:

• (end) users;

• installation engineers;

• service and maintenance engineers.

Symbols on each page indicate the target groups for whom the information is

intended. See the table.

Target group symbols

1.5 Maintenance A service should be carried out at least once a year, both on the water side and

on the gas side. Maintenance frequency depends, among other things, on the

water quality, the average burning time per day and the set water temperature.

Note

To determine the correct maintenance frequency, it is recommended to

arrange for the service and maintenance engineer to check the appliance on

both the water and gas side within three months following installation. Based on

this check, the best maintenance frequency can be determined.

Note

Regular maintenance extends the service life of the appliance.

Note

Both the end user and the service and maintenance engineer are

responsible for regular maintenance. They will need to establish clear

agreements on this.

Note

If the appliance is not regularly maintained, the warranty will become void.

1.6 Forms of notation The following notation is used in this manual:

Note

Important information.

Caution

Ignoring this information can lead to the appliance being damaged.

Warning

Failure to carefully read this information may lead to personal injury and

serious damage to the appliance.

Symbol Target group

(End) user

Installation engineer

Service and maintenance engineer

Instruction manual ADM 9

gis

1.7 Overview of this

document

The table provides an overview of the contents of this document.

Contents of this document

Chapter Target groups Description

Working principle of the

appliance

This chapter describes how the appliance functions.

Installation This chapter describes the installation activity to be

completed before you actually start up the appliance.

Filling This chapter describes how to fill the appliance.

Draining This chapter describes how to drain the appliance.

The control panel This chapter describes the general operation of the

appliance and explains how to use the control panel.

Status of the appliance This chapter describes the status (mode or condition) that

the appliance may have, and possible actions to take.

Starting and running This chapter describes how to start the appliance running.

The general heating cycle of the appliance is also

described.

Shutting down This chapter describes how to shut the appliance down for

a brief or long period of time.

Troubleshooting This chapter is mainly intended for the installation

engineer and the service and maintenance engineer. It

describes appliance errors. A table is included stating

potential symptoms, causes and solutions. End users

may also refer to this chapter for additional information

about the appliance.

Performing maintenance This chapter sets out the maintenance tasks to be carried

out during a service.

Warranty (certificate) This chapter states the warranty terms and conditions.

Introduction

10 Instruction manual ADM

1gis

Other manuals for ADM - 40

This manual suits for next models

Table of contents

Other A.O. Smith Water Heater manuals

A.O. Smith

A.O. Smith ACVT-50 100 User manual

A.O. Smith

A.O. Smith CYCLONE Xi BTH 400A Manual

A.O. Smith

A.O. Smith ARGSS02306 User manual

A.O. Smith

A.O. Smith DURA-Power DRE-52 User manual

A.O. Smith

A.O. Smith EWJ 15 User manual

A.O. Smith

A.O. Smith GAS WATER HEATER Product information sheet

A.O. Smith

A.O. Smith GPD-40 User manual

A.O. Smith

A.O. Smith THR-160 Product information sheet

A.O. Smith

A.O. Smith DRE 52 User manual

A.O. Smith

A.O. Smith 120-Gallon User manual

A.O. Smith

A.O. Smith Conservationist BTPV 650A Guide

A.O. Smith

A.O. Smith BTI 100 G Guide

A.O. Smith

A.O. Smith GPSX-50L User manual

A.O. Smith

A.O. Smith GPVL-50 How to use

A.O. Smith

A.O. Smith LB-500 User manual

A.O. Smith

A.O. Smith Dura-Power DRE - 120 User manual

A.O. Smith

A.O. Smith SGE - 40 Troubleshooting guide

A.O. Smith

A.O. Smith BTI - 65 Guide

A.O. Smith

A.O. Smith FPSH - 75 User manual

A.O. Smith

A.O. Smith BTX 100 How to use

A.O. Smith

A.O. Smith XVRL-40 Product information sheet

A.O. Smith

A.O. Smith COF 199 Troubleshooting guide

A.O. Smith

A.O. Smith 505 User manual

A.O. Smith

A.O. Smith ATI-305-N User manual

Popular Water Heater manuals by other brands

Kenmore

Kenmore 153.582400 Use & care guide

Applimo

Applimo Edel AIR Installation and operating instructions

STIEBEL ELTRON

STIEBEL ELTRON Eltronom SHU 5 S Operating and installation instructions

clage

clage E-Mini Series Operating and installation instructions

Toyotomi

Toyotomi Oil Miser OM-180 installation manual

Bradford White

Bradford White EF Series Service manual

Eccotemp

Eccotemp 40-H Use & care manual

Dimplex

Dimplex ECSd125-580 Installation and user instructions

Dux

Dux 32FCR6N installation manual

Toyotomi

Toyotomi Oil Miser OM-148 (Type D) Operation and maintenance instructions

Noritz

Noritz N-132M Owner's guide and installation manual

TESY

TESY GCV7/4S 10047 Instructions for use and maintenance

Koryo

Koryo KWHZF15Y user manual

Pentair

Pentair PSC-14-4-02 Installation and operation manual

GE 40M06AAG Energy guide

Thermor

Thermor AEROMAX SPLIT 2 Instructions for use

American Hometec

American Hometec AHQ-B03X Installation and operation manual

PVI

PVI MAXIM Specifications
