4 Moms Origami 4M-006-01 User manual
Contents
Afx seat ring to stroller frame at handle bar and power pod
by sliding pin through holes until it clicks. Buckle the seat
restraint strap around the Central Bar.
Turn the silver ring counterclockwise until it stops. Let go and
press the orange button. Make sure your silver activation ring
is unlocked.
To attach the Storage Bag,
snap the bag's straps into
place on the Central Bar.
If needed, use outlet on
underside of power pod to
plug stroller into the wall. Only
use provided charging cable.
Congratulations on your new Origami™!
Here are some helpful hints to get you started.
POWER FOLD
INSTALL SEAT RING
STORAGE BAG CHARGE
12
English
Table of Contents
Chapter 1: Safety Information. . . . . . . . . . . . . . . . . . . 4
Chapter 2: Seat Ring Safety . . . . . . . . . . . . . . . . . . . . 7
Chapter 3: Battery Warning . . . . . . . . . . . . . . . . . . . . 8
Chapter 4: Parts Guide . . . . . . . . . . . . . . . . . . . . . . . 9
Chapter 5: Installing the Handlebars . . . . . . . . . . . .11
Chapter 6: Installing the Seat Ring . . . . . . . . . . . . . 12
Chapter 7: Using Your Origami . . . . . . . . . . . . . . . . . 14
Chapter 8: Securing Your Baby. . . . . . . . . . . . . . . . . .15
Chapter 9: The LCD . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Chapter 10: Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Chapter 11: Using the Brakes . . . . . . . . . . . . . . . . . . . .17
Chapter 12: Seat Recline and Storage Bag . . . . . . . .18
Chapter 13: Folding the Stroller Manually. . . . . . . . . . 20
Chapter 14: Charging the Battery Manually . . . . . . . 22
Chapter 15: Maintaining Your Origami . . . . . . . . . . . . 23
Chapter 16: Troubleshooting. . . . . . . . . . . . . . . . . . . . .24
Chapter 17: Warranty . . . . . . . . . . . . . . . . . . . . . . . . . .26
Chapter 18: Registration. . . . . . . . . . . . . . . . . . . . . . . . 26
Chapter 19: Compliance. . . . . . . . . . . . . . . . . . . . . . . 27
4
Chapter 1: Important Safety Instructions
Please read these instructions carefully before
use and keep them for future reference. For your
child’s safety, please make sure anyone else using
the Origami Stroller reads and understands these
instructions before using it as well.
Immediately discontinue use of the stroller should it
become damaged or broken.
Using a stroller with your child presents inherent
safety risks. However, these risks can be minimized
with proper use. Please read this manual carefully
before using the stroller, as well as the manuals
for any Origami accessories you may be using,
and follow all safety instructions to avoid injury to
yourself or your child.
WARNING Use only 4moms® approved
accessories specically designed to work with the
model number of your base. Use of unapproved
accessories may cause injury or damage your
stroller.
ALWAYS use the Origami Seat Ring or
other 4moms® approved seating accessory. Read
all instructions included with 4moms® accessories
before use.
WARNING: NEVER leave your
child unattended. It may be dangerous to leave
your child unattended.
Before every use of the Origami, make sure the
stroller is fully open and securely latched.
5
English
Chapter 1: Important Safety Instructions
Always stay in control of the Origami’s movement.
Any wheeled vehicle can roll unpredictably, so
always stay within arm’s reach of the stroller. Keep
the stroller balanced: do not hang heavy objects
off the Handlebar, or allow children to play with
or hang off the Handlebar. Never allow a child to
push the Origami. Use the brake every time you
stop to prevent unexpected movement, especially
on inclines and when your child is getting into or
out of the stroller.
WARNING Any load attached to the
handle affects the stability of the stroller. Make sure
the Origami is stable and still when your child is
getting in or out. Always assist your child when he is
getting in or out, and hold on to the stroller to make
sure it doesn’t tip. Always use the brake when
stopped.
Be aware of the environment in which you are
using the Origami. Do not stroll over obstacles in
your path, and be especially careful on uneven,
slippery, or unstable terrain, as this may increase
the stroller’s likelihood of tipping. Make sure your
child’s arms and legs are inside the stroller before
moving, as obstructions striking the stroller could
cause injury.
Be careful when using the Origami on a steep
incline, as this increases the stroller’s likelihood of
tipping or rolling away from you. Never use the
Origami on stairs or escalators, or in any other
environment where you could suddenly lose control
of the stroller and cause injury to yourself or others.
the storage bag.
6
English
WARNING Use this stroller only for
walking. The Origami is not designed for jogging,
running, roller skating, or any motion other than an
adult’s walking pace. Do not let a child push the
Origami.
WARNING Ensure that the stroller
latches are engaged before use.
Always use your best judgment when using the
Origami. Do not use it in any situation in which
you suspect doing so could cause harm to your
child, yourself, or anyone around you. Stop using
the Origami immediately if you suspect any part
is damaged or not working correctly, or if the LCD
presents an “error” message, and contact 4moms
Customer Service for assistance.
AVOID STRANGULATION.
DO NOT place items with a string around
your child’s neck, suspend strings from this product,
or attach strings to toys.
TO AVOID BURNS, never put hot
liquids in the parent’s or child’s cup holders.
WARNING Do not store more than 10
pounds of material in the storage bag. The storage
bag is not a seating device. Never allow a child to
sit or lay in the storage bag. Do not store more than
1 pound in any of the 4 cupholders or more than 5
pounds in the seat back pockets. Excess weight
in any of these areas may create a hazardous,
unstable condition.
TO AVOID FINGER
ENTRAPMENT Use care when folding
and unfolding the stroller.
Chapter 1: Important Safety Instructions
7
English
English
Chapter 2: Seat Ring Safety Instructions
WARNING Avoid serious injury from
falling or sliding out. Always use restraints and
adjust belts to get a snug t around your child.
WARNING This seat unit is not
suitable for children under 6 months.
The Origami seat ring is designed for a single child.
Do not use for more than one child.
When using the seat ring,
NEVER PLACE child in the stroller
upside down or backwards. Child should
always be sitting up and facing forward.
WARNING Always use the crotch
strap in combination with the waist belt.
WARNING Before your rst use of
the Origami Stroller, make sure the Seat Ring
is properly attached to the Origami Base.
The seat ring should only be assembled by
an adult. Before each use, make sure the
seat lock pins are properly secured.
When using the seat ring, make sure your child is
securely fastened with the Safety Harness every time
you use the stroller. The seat ring is for children at
least 6 months old or able to sit up on their own. The
seat ring’s weight limit is 40 lbs (18 kgs). Do not use
the seat ring with a child who weighs over 40 lbs.
Chapter 2: Seat Ring Safety Instructions
8
Warnings
The Origami contains a Lithium Polymer battery
pack. Use only battery pack 4M-106-11-000101 or
a 4moms® approved equivalent. NEVER use
non-rechargeable batteries in the Origami.
Failure to follow instructions or use of non-approved
batteries could cause permanent damage to the
battery and its surroundings, and cause bodily harm.
Chapter 3: Battery Warnings
NEVER use anything EXCEPT a 4moms®
approved power supply to charge the
Origami Stroller.
NEVER trickle charge, or allow to discharge
below 2.5V per cell.
NEVER allow metal objects to contact battery
terminals.
NEVER allow the battery temperature to
exceed 140°F (60°C)
NEVER disassemble or modify pack wiring in
any way or puncture cells.
NEVER place on combustible materials or
leave unattended during charge.
ALWAYS keep battery pack out of reach of
children.
ALWAYS dispose of in accordance with local
laws.
Remove and replace battery pack when
product is stored for long periods of time or
when batteries are no longer functioning
properly.
•
•
•
•
•
•
•
•
•
9
English
Chapter 4: Parts Guide
Power
Pod
LCD
Central Bar
Seat Recline Strap
(see page #18)
Upper
Attachment
Hub
Handlebar
Storage Bag Loops
Manual Folding Latch
(see page # 21)
Charger
(see page #22)
Sunshade
Peek-A-Boo
Window
Power Button
Outer Ring
Brake
10
Chapter 4: Parts Guide (Seat Ring)
Safety Harness
Cup holders
Telescoping Frame
Upper Attachment Socket
Lower
Attachment
Hub
Seat
Release
Button
Pin
Storage Bag
Crotch Restraint
