3Com WL-602 User manual
http://www.3Com.com/
Part No. 10016790 Rev. AA
Published July 2008
Wireless 11n Cable/DSL Firewall Router
User Guide
WL-602
3CRWER300-73
3Com Corporation
350 Campus Drive,
Marlborough, MA
USA 01752-3064
Copyright © 2004, 2005, 2006, 2007, 2008, 3Com Corporation. All rights reserved. No part of this
documentation may be reproduced in any form or by any means or used to make any derivative work (such as
translation, transformation, or adaptation) without written permission from 3Com Corporation.
3Com Corporation reserves the right to revise this documentation and to make changes in content from time
to time without obligation on the part of 3Com Corporation to provide notification of such revision or change.
3Com Corporation provides this documentation without warranty, term, or condition of any kind, either
implied or expressed, including, but not limited to, the implied warranties, terms or conditions of
merchantability, satisfactory quality, and fitness for a particular purpose. 3Com may make improvements or
changes in the product(s) and/or the program(s) described in this documentation at any time.
If there is any software on removable media described in this documentation, it is furnished under a license
agreement included with the product as a separate document, in the hard copy documentation, or on the
removable media in a directory file named LICENSE.TXT or !LICENSE.TXT. If you are unable to locate a copy,
please contact 3Com and a copy will be provided to you.
UNITED STATES GOVERNMENT LEGEND
If you are a United States government agency, then this documentation and the software described herein are
provided to you subject to the following:
All technical data and computer software are commercial in nature and developed solely at private expense.
Software is delivered as “Commercial Computer Software” as defined in DFARS 252.227-7014 (June 1995) or
as a “commercial item” as defined in FAR 2.101(a) and as such is provided with only such rights as are
provided in 3Com’s standard commercial license for the Software. Technical data is provided with limited rights
only as provided in DFAR 252.227-7015 (Nov 1995) or FAR 52.227-14 (June 1987), whichever is applicable.
You agree not to remove or deface any portion of any legend provided on any licensed program or
documentation contained in, or delivered to you in conjunction with, this User Guide.
Unless otherwise indicated, 3Com registered trademarks are registered in the United States and may or may not
be registered in other countries.
3Com, and the 3Com logo are registered trademarks of 3Com Corporation.
Intel and Pentium are registered trademarks of Intel Corporation. Microsoft, MS-DOS, Windows, and Windows
NT are registered trademarks of Microsoft Corporation. Novell and NetWare are registered trademarks of
Novell, Inc. UNIX is a registered trademark in the United States and other countries, licensed exclusively
through X/Open Company, Ltd.
Netscape Navigator is a registered trademark of Netscape Communications.
JavaScript is a trademark of Sun Microsystems
Wi-Fi and the Wi-Fi logo are registered trademarks of the WI-Fi Alliance.
IEEE and 802 are trademarks of the Institute of Electrical and Electronics Engineers, Inc.
All other company and product names may be trademarks of the respective companies with which they are
associated.
ENVIRONMENTAL STATEMENT
It is the policy of 3Com Corporation to be environmentally-friendly in all operations. To uphold our policy, we
are committed to:
Establishing environmental performance standards that comply with national legislation and regulations.
Conserving energy, materials and natural resources in all operations.
Reducing the waste generated by all operations. Ensuring that all waste conforms to recognized environmental
standards. Maximizing the recyclable and reusable content of all products.
Ensuring that all products can be recycled, reused and disposed of safely.
Ensuring that all products are labelled according to recognized environmental standards.
Improving our environmental record on a continual basis.
End of Life Statement
3Com processes allow for the recovery, reclamation and safe disposal of all end-of-life electronic components.
Regulated Materials Statement
3Com products do not contain any hazardous or ozone-depleting material.
Environmental Statement about the Documentation
The documentation for this product is printed on paper that comes from sustainable, managed forests; it is
fully biodegradable and recyclable, and is completely chlorine-free. The varnish is environmentally-friendly, and
the inks are vegetable-based with a low heavy-metal content.
CONTENTS
ABOUT THIS GUIDE
Naming Convention 7
Conventions 8
Feedback About This User Guide 9
Related Documentation 9
INTRODUCING THE ROUTER
Wireless 11n Cable/DSL Firewall Router 11
Router Advantages 13
Package Contents 13
Minimum System and Component Requirements 14
Physical Features 14
INSTALLING THE ROUTER
Introduction 19
Safety Information 19
Positioning the Router 19
Using the Rubber Feet 20
Wall Mounting 20
Mounting Instructions for Cement Walls 20
Mounting Instructions for Wood Walls 21
Powering Up the Router 21
Connecting the Router 21
SETTING UPYOUR COMPUTERS
Obtaining an IP Address Automatically 23
Windows 2000 23
Windows Vista 25
Windows XP 26
Macintosh 26
Disabling PPPoE and PPTP Client Software 27
Disabling Web Proxy 27
RUNNING THE SETUP WIZARD
Accessing the Router using the 3Com Detect Application 29
Running the 3Com Detect Application 29
Accessing the Setup Wizard 31
Wizard -
Change Password 34
Wizard -
Time and Time Zone 35
Wizard -
Connection Type 36
Setup Wizard - LAN Settings 42
Wizard - Wireless Setting 43
Wizard - Configuration Summary 49
CONFIGURING THE ROUTER
Navigating Through the Router Configuration screens 51
Main Menu 51
Welcome Screen 51
Status 51
LAN Settings 52
LAN Settings 52
DHCP Clients List 53
Wireless Settings 55
Configuration 56
Encryption 57
WPS 62
Connection Control 64
Client List 65
WMM 65
WDS 68
Advanced 71
Internet Settings 73
WAN 73
DNS 79
Clone MAC address 80
Firewall 81
SPI 81
Special Applications 85
Virtual Servers 86
DMZ 87
PC Privileges 88
Schedule Rule 90
URL Filter 91
Advanced 92
Security 92
VLAN 95
Static Routes 97
RIP 99
DDNS 101
SNMP 102
Syslog 103
Proxy ARP 104
QoS Settings 105
Traffic mapping 106
VPN 108
System Tools 115
Restart Router 115
Configuration 115
Upgrade 116
Time Zone 117
Ping 118
Traceroute 119
DNS Lookup 120
Diagnostic 120
Status and Logs 121
Status 121
Routing Table 122
Logs 122
Traffic Statistics 123
Support/Feedback 124
Support 124
Feedback 124
TROUBLESHOOTING
Basic Connection Checks 125
Browsing to the Router Configuration Screens 126
Connecting to the Internet 127
Forgotten Password and Reset to Factory Defaults 127
Wireless Networking 128
Recovering from Corrupted Software 130
Power Adapter 130
Frequently Asked Questions 132
IP ADDRESSING
The Internet Protocol Suite 133
Managing the Router over the Network 133
IP Addresses and Subnet Masks 133
How does a Device Obtain an IP Address and Subnet Mask? 135
DHCP Addressing 135
Static Addressing 135
Auto-IP Addressing 135
TECHNICAL SPECIFICATIONS
3Com Wireless 11n Cable/DSL Firewall Router 137
Standards 139
SAFETY INFORMATION
END USER SOFTWARE LICENSE AGREEMENT
OBTAINING SUPPORT FOR YOUR 3COM PRODUCTS
Register Your Product to Gain Service Benefits 148
Solve Problems Online 148
Purchase Extended Warranty and Professional Services 148
Access Software Downloads 149
Contact Us 149
Telephone Technical Support and Repair 149
GLOSSARY
REGULATORY NOTICES
INDEX
ABOUT THIS GUIDE
This guide describes how to install and configure the 3Com Wireless 11n
Cable/DSL Firewall Router (3CRWER300-73).
This guide is intended for use by those responsible for installing and
setting up network equipment; consequently, it assumes a basic working
knowledge of LANs (Local Area Networks) and Internet Routers.
If a release note is shipped with the 3Com Wireless 11n Cable/DSL
Firewall Router and contains information that differs from the
information in this guide, follow the information in the release note.
Most user guides and release notes are available in Adobe Acrobat
Reader Portable Document Format (PDF) on the 3Com World Wide Web
site:
http://www.3Com.com
Naming Convention Throughout this guide, the 3Com Wireless 11n Cable/DSL Firewall Router
is referred to as the “Router”.
Category 3, Category 5, and Category 6 Twisted Pair Cables are referred
to as Twisted Pair Cables throughout this guide.
8ABOUT THIS GUIDE
Conventions Table 1 and Ta b l e 2 list conventions that are used throughout this guide.
Table 1 Notice Icons
Icon Notice Type Description
Information note Information that describes important features or
instructions.
Caution Information that alerts you to potential loss of data or
potential damage to an application, system, or device.
Warning Information that alerts you to potential personal
injury.
Table 2 Text Conventions
Convention Description
The words “enter”
and “type”
When you see the word “enter” in this guide, you must type
something, and then press Return or Enter. Do not press
Return or Enter when an instruction simply says “type.”
Keyboard key names If you must press two or more keys simultaneously, the key
names are linked with a plus sign (+). Example:
Press Ctrl+Alt+Del
Words in italics Italics are used to:
■Emphasize a point.
■Denote a new term at the place where it is defined in the
text.
■Identify menu names, menu commands, and software
button names. Examples:
From the Help menu, select Contents.
Click OK.
