DATA SHEET

3Com®Baseline Switches

Wide-Ranging Unmanaged Family

Small to mid-sized businesses looking for a

switched LAN with or without high-speed

uplinks, or a low cost, high-performance

Gigabit network, will find an affordable

solution with the family of 3Com®Baseline

switches, designed for plug-and-play

network operation.

10/100 Switching with Legacy Support

3Com Baseline Switch 2016 and 2024 are

ideal for businesses with legacy Ethernet

desktops that want to start a network. Fast

Ethernet (100 Mbps) support easily handles

higher speed desktop and office server

connections.

High-Performance 10/100/1000

Switching

For top performance, the 3Com Baseline

Switch 2808, 2816 and 2824 deliver wire-

speed Gigabit throughput and a switching

capacity of up to 48 Gbps to handle the

most bandwidth-hungry applications.

Plug-and-Play Unmanaged Operation

3Com Baseline switches operate straight

out of the box, with no configuration

required. Auto MDI/MDIX ports identify

and adapt to the Ethernet cable type, elim-

inating the most common cabling errors

and simplifying installation. Autosensing

ports detect and adjust to the speed of the

connected device to optimize network

performance.

Rack-Mounted or Free-Standing

Configuration

Small-business configurations can vary, so

the switches are designed to operate as a

free-standing or rack-mounted switch

with included mounting kit. The standard

19-inch, one rack-unit-high (1 RU) enclo-

sure optimizes valuable office space.

Warranty

Limited Lifetime Hardware Replacement. See

www.3com.com/warranty for more detail.

Key Benefits

• Feature-rich devices with

wirespeed, non-blocking

performance

• Advanced features, such as

support for traffic prioritization

are ideal for larger networks,

running real-time applications

• Easy installation, with

plug-and-play design

3COM®BASELINE SWITCHES DATA SHEET

3Com Baseline Switches at a Glance

3C16470 3C16471 3C16472 3C16477A 3C16478 3C16479

Ports - Autosensing 16 10/100 24 10/100 24 10/100 and 8 10/100/1000 16 10/100/1000 24 10/100/1000

Ethernet Ethernet 2 10/100/1000 Ethernet Ethernet Ethernet

Ethernet

LED Indicators Power, Network Power, Network Power, Network Power, Network Power, Network Power, Network

traffic/Duplex traffic/Duplex traffic/Duplex traffic/Duplex traffic/Duplex traffic/Duplex

mode, Link mode, Link mode, Link mode, Link mode, Link mode, Link

status/Speed status/Speed status/Speed status/Speed status/Speed status/Speed

802.1p Traffic N/A N/A N/A 4 queues on 4 queues on 4 queues on

Prioritization every port every port every port

(Priority Queuing)

MAC Addresses 4,000 4,000 4,000 8,000 32,000 32,000

MDI/MDIX - ✓✓✓✓✓✓

Automatic

configuration

on all ports

Forwarding Store & Forward Store & Forward Store & Forward Store & Forward Store & Forward Store & Forward

Method

3COM BASELINE

SWITCH 2016

3COM BASELINE

SWITCH 2024

3COM BASELINE

SWITCH 2126-G

3COM BASELINE

SWITCH 2808

3COM BASELINE

SWITCH 2816

3COM BASELINE

SWITCH 2824

Description

POWERFUL, ADVANCED SWITCHING

Gigabit performance (3C16472, 3C16477A, Connect to servers and desktops running at 10, 100, or 1000 Mbps. 48 Gbps switching capacity supports

3C16478, 3C16479) highest speed servers and desktops without additional network investment.

Non-blocking performance Baseline switches operate at full wirespeed on all ports, delivering unimpeded access to

networked resources.

Cost-effective 10/100/1000 connections Range of port densities provides expansion for growing small businesses at a very affordable price per port.

SIMPLE INSTALLATION AND USE

Auto MDI/MDIX ports Simplify installation by eliminating common cabling errors, automatically detecting the type of Ethernet

cable used—straight-through or crossover.

Pre-configured setup Makes sure that switches work "right out of the box" with no configuration or management

software needed.

Easy-to-read front panel LEDs Give at-a-glance status and network information to simplify diagnostics and troubleshooting.

Consistent form factor Clean design, standard 1RU enclosure optimizes rack space.

RELIABLE

Sturdy, dependable design 3Com delivers premium-quality, reliable networking products that stay up and running year after year.

Complete support package Limited Lifetime Hardware Replacement provides peace of mind.

Features and Benefits

Specifications Total Ports

3C16470: 16 autosensing 10/100

3C16471: 24 autosensing 10/100

3C16472: 24 autosensing 10/100 and 2 autosensing

10/100/1000

3C16477A: 8 autosensing 10/100/1000

3C16478: 16 autosensing 10/100/1000

3C16479: 24 autosensing 10/100/1000

Standards Conformance

ISO 8802-3

IEEE 802.3 (Ethernet)

IEEE 802.3u (Fast Ethernet)

IEEE 802.1d (bridging)

IEEE 802.3x (flow control)

IEEE 802.3ab (Gigabit Ethernet)

IEEE 802.1p (traffic prioritization)

Media Interfaces

10/100/1000BASE-TX/RJ-45

MAC Addresses

3C16470, 3C16471, 3C16472: 4000

3C16477A: 8000

3C16478 and 3C16479: 32,000

Ethernet Switching Features

Wirespeed, non-blocking Layer 2 switching; Store-

and-forward forwarding; Full-/half-duplex

auto-negotiation; 802.1p traffic prioritization

(priority queuing)

Electrical Power

Power inlet: IEC 320

AC line frequency: 47/63 Hz

Input voltage: 100-240 VAC

Current rating: 1A (max)

Maximum power consumption:

3C16470 – 15W,

3C16471 – 20W,

3C16472 - 12.5 W

3C16477A – 9.96W,

3C16478 – 26.3W,

3C16479 – 35.04W

Maximum power dissipation:

3C16470 – 52 BTU/hr,

3C16471 – 68 BTU/hr,

3C16472 - 42.56 BTU/hr

3C16477A – 34.02 BTU/hr,

3C16478 – 89.8 BTU/hr,

3C16479 – 119.7 BTU/hr

LED Indicators

Power, Network traffic/Duplex mode,

Link status/Speed

Operating Temperature:

0° to 40°C (32° to 104°F)

Humidity: 10 to 90% (non-condensing)

Safety

UL 1950, EN 60950, CSA 22.2 #950 IEC 60950

Emissions

EN 55022 Class A, FCC Part 15 Subpart B Class A,

ICES-003 Class A, VCCI Class A,

AS/NZS 3548 Class A, CNS 13438 Class A

Environmental

EN 60068 (IEC 68)

Immunity

EN 55024

Physical Dimensions

Height: 4.4 cm (1.7 in)

Depth: 17.3 cm (6.8 in)

Width: 44 cm (17.3 in)

Weight: 3C16470, 3C16471 and 3C16477A – 1.5 kg

(3.07 lb);

3C16472 - 1.6 Kg (3.52 lb)

3C16478 – 1.87 kg (4.12 lb); 3C16479 – 1.96 kg (4.32 lb)

Package Contents

Baseline Switch

Rubber feet

Rack-mount kit

User’s guide

Warranty

Limited Lifetime Hardware Replacement

Other Service Benefits: Advance hardware replace-

ment with same day shipment for North America and

Western Europe. Next day shipment for rest of world.

Calls must be received by published cut-off times.

90 days of telephone technical support. Limited soft-

ware updates.

See www.3com.com/warranty for more detail.

3COM®BASELINE SWITCHES DATA SHEET

3Com Corporation, Corporate Headquarters, 350 Campus Drive, Marlborough, MA 01752-3064

To learn more about 3Com solutions, visit www.3com.com. 3Com is publicly traded on NASDAQ under the symbol COMS.

Corporation. All other company and product names may be trademarks of their respective companies. While every effort is made

to ensure the information given is accurate, 3Com does not accept liability for any errors or mistakes which may arise.

Specifications and other information in this document may be subject to change without notice. 400838-005 06/05

3COM®BASELINE SWITCHES DATA SHEET

Ordering Information All Baseline switches include:

• Plug and play simplicity

• No configuration required

• Compact 1RU-high enclosure

• Easy installation and upgrade rack

mounting kit

• Free-standing or 19-inch rack-mounted

operation

PRODUCT DESCRIPTION 3COM SKU

3Com Baseline Switch 2016 3C16470

3Com Baseline Switch 2024 3C16471

3Com Baseline Switch 2126-G 3C16472

3Com Baseline Switch 2808 3C16477A

3Com Baseline Switch 2816 3C16478

3Com Baseline Switch 2824 3C16479
