VOX electronics LARDER KS-1210 User manual

KS-1210 KS- 1220

OPERATING INSTRUCTIONS LARDER

UPUTSTVO ZA UPOTREBU FRIŽIDER

NAVODILA ZA UPORABO HLADILNIK

UPUTE ZA UPORABU HLADNJAK

MANUAL DE USUARIO FRIGORÍFICO

MANUAL DO USUÁRIO FRIGORÍFICO

GBR

SRB

SVN

HRV

ESP

PRT

User manual

Larder KS 1210

KS 1220

Content

Safety Information

Page 1~5

Overview

Page 6

3. Reverse Door

Page 7~8

Installation

Page 9~10

Daily Use

Page 11~13

GBR

Safety information

In the interest of your safety and to ensure the correct use, before

installing and first using the appliance, read this user manual carefully,

including its hints and warnings. To avoid unnecessary mistakes and

accidents, it is important to ensure that all people using the appliance

are thoroughly familiar with its operation and safety features. Save

these instructions and make sure that they remain with the appliance if

it is moved or sold, so that everyone using it through its life will be

properly informed on appliance use and safety.

For the safety of life and property keep the precautions of these user’s

instructions as the manufacturer is not responsible for damages

caused by omission.

Children and vulnerable people safety

yThis appliance can be used by children aged from 8 years and above

and persons with reduced physical, sensory or mental capabilities or

lack of experience and knowledge if they have been given super

vision or instruction concerning use of the appliance in a safe way

and understand the hazards involved.

yChildren aged from 3 to 8 years are allowed to load and unload this

appliance.

yChildren should be supervised to ensure that they do not play with

the appliance.

yCleaning and user maintenance shall not be made by children unless

they are aged from 8 years and above and supervised.

yKeep all packaging well away from children. There is risk of

suffocation.

yIf you are discarding the appliance pull the plug out of the socket, cut

the connection cable (as close to the appliance as you can) and

remove the door to prevent playing children to suffer electric shock or

to close themselves into it.

yIf this appliance featuring magnetic door seals is to replace an older

appliance having a spring lock (latch) on the door or lid, be sure to

make that spring lack unusable before you discard the old appliance.

This will prevent it from becoming a death trap for a child.

General safety

WARNING! Keep ventilation openings, in the appliance enclosure

or in the built-in structure, clear of obstruction.

WARNING! Do not use mechanical devices or other means to

accelerate the defrosting process, other than those recommended

by the manufacturer.

WARNING! Do not damage the refrigerant circuit.

Safety information

WARNING! Do not use other electrical appliances (such as ice

cream makers) inside of refrigerating appliances, unless they are

approved for this purpose by the manufacture.

WARNING! Do not touch the light bulb if it has been on for a long

period of time because it could be very hot.1 )

yDo not store explosive substances such as aerosol cans with a

flammable propellant in this appliance.

The refrigerant isobutane (R-600a) is contained within the refrigerant

circuit of the appliance, a natural gas with a high level of

environmental compatibility, which is nevertheless flammable.

During transportation and installation of the appliance, be certain

that none of the components of the refrigerant circuit become

damaged.

- avoid open flames and sources of ignition

- thoroughly ventilate the room in which the appliance is situated

It is dangerous to alter the specifications or modify this product in any

way. Any damage to the cord may cause a short circuit, fire and/or

electric shock.

This appliance is intended to be used in household and similar

applications such as

- staff kitchen areas in shops, offices and other working

environments;

- farm houses and by clients in hotels, motels and other residential

type environments;

- bed and breakfast type environments;

- catering and similar non-retail applications.

WARNING! Any electrical components(plug, power cord,

compressor and etc.) must be replaced by a certified service agent

or qualified service personnel.

WARNING! The light bulb supplied with this appliance is a “special

use lamp bulb” usable only with the appliance supplied. This “special

use lamp” is not usable for domestic lighting.1 )

1) If there is a light in the compartment.

WARNING! When positioning the appliance, ensure the supply

cord is not trapped or damaged.

WARNING! Do not locate multiple portable socket-outlets

portable power suppliers at the rear of the appliance.

Safety information

1) If there is a freezer compartment.

2) If there is a fresh-food storage compartment.

yPower cord must not be lengthened.

yMake sure that the power plug is not squashed or damaged by the

back of the appliance. A squashed or damaged power plug may

overheat and cause a fire.

yMake sure that you can come to the mains plug of the appliance.

yDo not pull the mains cable.

yIf the power plug socket is loose, do not insert the power plug. There

is a risk of electric shock or fire.

yYou must not operate the appliance without the lamp.

yThis appliance is heavy. Care should be taken when moving it.

yDo not remove nor touch items from the freezer compartment if you

hands are damp/wet, as this could cause skin abrasions or

frost/freezer burns.

yAvoid prolonged exposure of the appliance to direct sunlight.

yDo not put hot on the plastic parts in the appliance.

yDo not place food products directly against the rear wall.

yFrozen food must not be re-frozen once it has been thawed out.1 )

yStore pre-packed frozen food in accordance with the frozen food

manufacture,

s instructions.1 )

yAppliance,

s manufactures storage recommendations should be

strictly adhered to. Refer to relevant instructions.

yDo not place carbonated of fizzy drinks in the freezer compartment as

it creates pressure on the container, which may cause it to explode,

resulting in damage to the appliance.1 )

yIce lollies can cause frost burns if consumed straight from the

appliance.1)

To avoid contamination of food, please respect the following

instructions

yOpening the door for long periods can cause a significant increase

the temperature in the compartments of the appliance.

yClean regularly surfaces that can come in contact with food and

accessible drainage systems.

yClean water tanks if they have not been used for 48h; flush the

water

system connected to a water supply if water has not been drawn

for 5

days.

yStore raw meat and fish in suitable containers in the refrigerator, so

that it is not in contact with or drip onto other food.

yTwo-star frozen-food compartments(if they are presented in the

appliance) are suitable for storing pre-frozen food, storing or

making

ice-cream and making ice cubes.

Safety information

1) If there is a freezer compartment.

2) If there is a fresh-food storage compartment.

Before maintenance, switch off the appliance and disconnect the

mains plug from the mains socket.

Do not clean the appliance with metal objects.

Do not use sharp objects to remove frost from the appliance. Use a

plastic scraper.1 )

Regularly examine the drain in the refrigerator for defrosted water. If

necessary, clean the drain. If the drain is blocked, water will collect in

te bottom of the appliance.2)

Installation

Important! For electrical connection carefully follow the instructions

given in specific paragraphs.

Unpack the appliance and check if there are damages on it. Do not

connect the appliance if it is damaged. Report possible damages

immediately to the place you bought it. In that case retain packing.

It is advisable to wait at least four hours before connecting the

appliance to allow the oil to flow back in the compressor.

Adequate air circulation should be around the appliance, lacking this

leads to overheating. To achieve sufficient ventilation follow the

instructions relevant to installation.

Wherever possible the spacers of the product should be against a

wall to avoid touching or catching warm parts (compressor, con-

denser) to prevent possible burn.

The appliance must not be located close to radiators or cookers.

Make sure that the mains plug is accessible after the installation of

the appliance.

Any electrical work required to do the servicing of the appliance

should be carried out by a qualified electrician or competent person.

This product must be serviced by an authorized Service Center, and

only genuine spare parts must be used.

Don’t put hot food in the appliance;

Don’t pack food close together as this prevents air circulating;

Make sure food don’t touch the back of the compartment(s);

yOne-, two- and three -star compartments (if they are presented in the

appliance) are not suitable for the freezing of fresh food.

If the appliance is left empty for long periods, switch off, defrost,

clean, dry and leave the door open to prevent mount developing

within the appliance.

Safety information

If electricity goes off, don’t open the door(s);

Don’t open the door(s) frequently;

Don’t keep the door(s) open for too long time;

Don’t set the thermostat on exceeding cold temperatures;

Some accessaries, such as drawers, can be removed to get larger

storage volume and lower energy consumption.

This appliance does not contain gasses which could damage the

ozone layer, in either its refrigerant circuit or insulation materials. The

appliance shall not be discarded together with the urban refuse and

rubbish. The insulation foam contains flammable gases: the appliance

shall be disposed according to the appliance regulations to obtain from

your local authorities. Avoid damaging the cooling unit, especially the

heat exchanger. The materials used on this appliance marked by the

symbol are recyclable.

The symbol on the product or on its packaging indicates that this

product may not be treated as household waste. Instead it

should be taken to the appropriate collection point for the

recycling of electrical and electronic equipment. By ensuring this

product is disposed of correctly, you will help prevent potential

negative consequences for the environment and human health, which

could otherwise be caused by inappropriate waste handling of this

product. For more detailed information about recycling of this product,

please contact your local council, your household waste disposal

service or the shop where you purchased the product.

Packaging materials

The materials with the symbol are recyclable. Dispose the packaging in

a suitable collection containers to recycle it.

Disposal of the appliance

1. Disconnect the mains plug from the mains socket.

2. Cut off the mains cable and discard it.

WARNING! During using, service and disposal the

appliance, please pay attention to symbol similar as left side,

which is located on rear of appliance (rear panel or compressor)

and with yellow or orange color.

It’s risk of fire warning symbol. There are flammable materials in

refrigerant pipes and compressor.

Please be far away fire source during using, service and

disposal.

Overview

Thermostat

and Light

Glass Shelves

Balconies

Crisper Cover

Crisper

Leveling Feet

ThisŠillustrationŠisŠonlyŠforŠhinting,ŠtheŠdetailŠpleaseŠcheckŠyourŠappliance.



Reverse Door

Tool required: Philips screwdriver, Flat bladed screwdriver, Hexagonal spanner.

yEnsure the unit is unplugged and empty. 



yTo take the door off, it is necessary to tilt the unit backwards. You should rest the unit on something solid so that

it will not slip during the door reversing process. 

yAll parts removed must be saved to do the reinstallation of the door. 

yDo not lay the unit flat as this may damage the coolant system. 

yIts better that 2 people handle the unit during assembly

1. Remove two screws at rear side of top cover.

unscrew

2. Remove top cover and place it aside.

3. Unscrew top hinge and then remove door and place it on a soft pad to

avoid scratch.

4. Unscrew bottom hinge. Then remove the adjustable feet from both side. Note: remove this screw if it presents.



Reverse Door

5. Unscrew and remove the bottom hinge pin, turn the bracket over and replace it.

Unscrew

Screw

6. Refit the bracket fitting the bottom hinge pin. Replace both adjustable feet.

7. Place the door back on. Ensure the door is aligned horizontally and

vertically, so that the seals are closed on all sides before finally

tightening the top hinge.

8. Put the top cover and fix it with 2 screws on the back.



This manual suits for next models

Table of contents

Languages:

Other VOX electronics Refrigerator manuals

VOX electronics

VOX electronics KG-2650 User manual

VOX electronics

VOX electronics NF 3833A User manual

VOX electronics

VOX electronics KS2110F User manual

VOX electronics

VOX electronics KS-1500 User manual

VOX electronics

VOX electronics KG-2500S User manual

VOX electronics

VOX electronics KS-325 User manual

VOX electronics

VOX electronics KK3220F User manual

VOX electronics

VOX electronics KS 3750 User manual

VOX electronics

VOX electronics KG-2730 User manual

VOX electronics

VOX electronics IKG-2600F User manual

VOX electronics

VOX electronics KS-0610 User manual

VOX electronics

VOX electronics IKS2790F User manual

VOX electronics

VOX electronics KK-3600 User manual

VOX electronics

VOX electronics KS-2110 User manual

VOX electronics

VOX electronics KS1430 User manual

VOX electronics

VOX electronics KK-3300 User manual

VOX electronics

VOX electronics KS1530 User manual

VOX electronics

VOX electronics KS-2510 User manual

VOX electronics

VOX electronics IVF2790F User manual

VOX electronics

VOX electronics KK-3400 User manual

VOX electronics

VOX electronics INF-3400 User manual

VOX electronics

VOX electronics KS-1110 User manual

VOX electronics

VOX electronics IKS1450F User manual

VOX electronics

VOX electronics KS-1461 User manual

Popular Refrigerator manuals by other brands

Bonnet Neve

Bonnet Neve SKYVIEW PLUS User instructions

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Instruction book

Sharp

Sharp SJ-BA31IEXW2-EU user manual

CORBERO

CORBERO CC2300MCW Instruction booklet

KitchenAid

KitchenAid 2205264 Use and care guide

Stengel

Stengel KU 1101 A++ user manual

NEFF

NEFF KI181 Series user manual

Hoshizaki

Hoshizaki Reach-In instruction manual

Amana

Amana ASD2524VES00 User instructions

BOMANN

BOMANN KGC 213 instruction manual

Danby

Danby DAR044A1SLDD Owner's use and care guide

Samsung

Samsung RF323TE user manual

Beko

Beko CSA31022 Instructions for use

IKEA

IKEA FROSTIG C 185 E manual

Electrolux

Electrolux ER 6821 D Instruction book

True

True TS-28 Specifications

Frigidaire

Frigidaire FSC23R5DW9 installation guide

Beko

Beko LSP4579W Instructions for use
