Vivo STAND-HS02W User manual

White Hand Sanitizer Floor Stand

Scan the QR code with your mobile device or follow the link

for helpful videos and specifications related to this product.

Instruction Manual

https://vivo-us.com/products/stand-hs02w

SKU: STAND-HS02W

[email protected]om www.vivo-us.com 309-278-5303

Chat live with an agent!

GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST

2

ASSEMBLY STEPS

STEP 1

Apply pads (E) to the underside of the base (A).

PACKAGE CONTENTS

TOOLS NEEDED

WARNING!

Phillips

Screwdriver

A (x1)

Base

B(x1)

Pole

C(x1)

Mounting

Plate

D (x1)

Drip Tray

If you do not understand these directions, or if you have any doubts about the safety of the

installation, please call a qualified technician. Check carefully to make sure there are no missing or

defective parts. Improper installation may cause damage or serious injury. Do not use this product

for any purpose that is not explicitly specified in this manual. Do not exceed weight capacity.

We cannot be liable for damage or injury caused by improper mounting, incorrect assembly or

inappropriate use.

WARNING: CHOKING HAZARD

SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS.

ADULT SUPERVISION IS REQUIRED.

E (x4)

Pad

F(x4)

M6x16

G(x1)

4mm Allen

Wrench

11lbs

(5kg)

DO NOT EXCEED WEIGHT CAPACITY.

Failure to do so may result in serious injury.

A

E

3

STEP 2

Assemble pole (B) to base (A) using x2 M6x16 bolts (F) and tighten with the 4mm Allen

wrench (G).

STEP 3

Assemble drip tray (D) and mounting plate

(C) to pole (B) using x2 M6x16 bolts (F) and

tighten with the 4mm Allen wrench (G).

Install hand sanitizer dispenser to the

mounting plate using hardware or adhesive

pads included with the dispenser.

B

F

G

D

CF

LAST UPDATED: 07/15/2020

Open Monday - Friday 7:00am - 7:00pm CST,

our dedicated support team can oer immediate assistance with rapid response times. If any

parts are received damaged or defective, please contact us. We are happy to replace parts to

ensure you have a fully functioning product.

FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com

[email protected] AVG. RESPONSE TIME (within oice hrs): 1HR 8M

- 23% within < 15m

- 38% within < 30m

- 61% within < 1hr

- 83% within < 2hr

- 92% within < 3hr

Love your new VIVO setup and want to share?

Tag us in your photo! @vivo_us

AVG. RESOLUTION TIME (within oice hrs): < 15 M

www.vivo-us.com

Chat live with an agent!

AVG. RESOLUTION TIME (within oice hrs): 5M 4S

309-278-5303
