Ublox EVK-C20 User manual
1. Connect wireless antenna to Wireless Antenna.
2. Connect GPS antenna to GPS Antenna (if required).
3. Connect power adapter to 9 – 18 V Power Input
connector (J400) (+12 V). LED DL401 lights blue.
4. To supply power to the board, turn Main Power
(SW400) switch to ON position. LED DL400 lights green.
5. To switch on the wireless module, press the
Module Power ON (SW302) button.
6. USB connection: Connect USB cable to LISA-C200
native USB connector
Alternative UART connections:
7. Connect USB cable to mini USB connector
(Wireless USB UART J501).
Switch SW403 must be in position MINIUSB.
8. Connect RS232 cable to RS232 connector
(Wireless Module UART RS232 J500).
Switch SW403 must be in position DB9.
Quick Start EVK-C20
2. Setup
Copyright © 2013, u-blox AG
1. Overview 7
6
1
3
4
5
2
8SW403
Native USB connection:
The USB driver creates 2 COM ports
(the numbering of the ports can be
seen via the Device Manager of Win-
dows). The serial port for AT com-
mands and data is available over the
highest numbered COM port opened
by the driver.
UART connection:
Two COM ports are enabled with
Windows (the numbering of the ports
can be seen via the Windows De-
vice Manager). The serial port for AT
commands is available over the first
numbered COM port opened by the
driver.
Refer to the EVK-C20 Getting Started
user guide in the EVK-C20\Documen-
tation folder for a comprehensive de-
scription of the evaluation kit features
and functionalities.
For more information regarding the
EVK-C20, contact your
nearest u-blox support:
www.u-blox.com/en/
contact-us-support.html
4. Interfaces
5. More information
CDMA-EK-13001
Download the newest version of the
EVK-C20 drivers and documents from
the u-blox website: www.u-blox.com/
evk-downloads
The installation software will automat-
ically start and guide you through the
installation process. The most up-to-
date components will be installed on
your system. When the installation is
complete, you can find these in the
Start > Programs > u-blox
menu.
3. Software
