Toshiba 20DL75 User manual

KEY FEATURES

ADVANTAGES

20DL75

20” LCD TELEVISIONS

• 640 x 480 VGA LCD Panel

• 400:1 Contrast Ratio

• 450 cd/m2 Brightness

• 176° Viewing Angle

• Glow remote control

• 480i/480p Video Input

Headphone Jack

Audio Video Inputs (1+1)

S Video Inputs (1)

• Surround Sound (4 modes)

ColorStream HD™ Inputs

The ColorStream™ Component Video signal is delivered in its base components (Y, Pr,Pb). Both inputs accept either 480i, 480p, 720p or 1080i sources.The signal is

unaffected by the TV’s tuner, comb filter or NTSC decoder. The TV is HDTV compatible and the user can connect both an HDTV STB source and progressive scan

DVD player. These connections are made even easier when combined with HDSC technology as the Auto Signal Sensor automatically detects the type of signal.

There are no menu settings to access or change for seamless and easy management for all signal types.

SPECIFICATION

VIDEO

DIMENSIONS

640 x 480 VGA LCD Panel

350:1 Contrast Ratio

450 cd/m2 Brightness

176 Degree viewing angle

25ms response speed

Auto Aspect Detection (480i/480p)

Picture Modes

3D Y/C comb filter

MTS/SAP

Surround Sound (4 modes)

WOW™ by SRS® Surround Sound

StableSound®

10 watt Audio Output

Glow remote control

Trilingual OSD

Sleep Timer

Channel Lock

Integrated Stand

VESA compatible

Closed Captioning

CONVENIENCE AUDIO

CONNECTIONS

Cabinet Dimensions (mm):

Carton (mm):

UPC:

(W) 490mm (H) 467mm (D) 227mm

22lbs

(W) 572mm (H) 562mm(D) 280mm

25 lbs

022265 240403

Headphone Jack

Audio Video Inputs (1+1)

S Video Inputs (1)

ColorStream inputs (1)

PC Audio Input (1)

RF Inputs (1)

20DL75

Specifications subject to change without notice.
