Speed Queen Tumble dryers User manual

ON-PREMISES LAUNDRY

Tumble Dryers

50 lb Tumble Dryer 75 lb Tumble Dryer

THE BEST IN CLASS JUST GOTBETTER.

100 years. It’s a long time for any company to be at the forefront of an industry. And you’d think that

a company that’s been able to lead for that long must have a finely honed craft — a premier product.

Well, you’d be right. For more than a century, Speed Queen has built a legacy on providing equipment

that stands up to any commercial laundry challenge. We make no compromises in performance. We

refuse to be outdone in reliability and efficiency. Our commitment to quality is only matched by our

commitment to your success. The result? The most profitable machines in the industry — bar none.

Some of our competitors may think that a residential machine wrapped in a rugged exterior passes

for commercial grade. We believe that strength comes from within. Speed Queen machines are built

specifically for the commercial environment. We use metal where others use plastic. Our world-

class Test Lab rigorously pushes our products far beyond the conditions they’ll face in the field. We

believe in being there when our customers need us most. And we go the extra mile at every point of

our manufacturing process to ensure that our machines reflect that belief.

For commercial laundry equipment designed for use in fire departments, health care facilities, hotels,

correctional facilities, spas, salons, athletics organizations or another industry application, you can

rely on the proven performance of Speed Queen to make your life simpler and more productive.

Made in America and refined for more than a century, Speed Queen Laundry equipment represents

a secure investment for your on-premises laundry facility.

DEDICATED TO A HIGHER STANDARD

DUAL DIGITAL

Set drying time, temperature and cool down. Features include

one touch cycle repeat,automatic extended tumble and large

digital countdown display.

QUANTUM GOLD

Quantum Gold offers three modes of operation (time, auto and

moisture dry) along with the flexibility of 30 programmable cycles

and optional moisture sensing technology (OPT) that prevents

over drying,saving time and energy.

Uncomplicated. Uncompromising. Unmatched. Enjoy heavy-duty construction that will provide

reliable operation for years to come.

Our single pocket tumble dryers feature a concentrated airflow pattern and sealed cylinder rims to

ensure maximum air utilization and energy savings. This superior drying performance helps laundries

maximize throughput to meet the daily workload without the need for added shifts or costly overtime.

Our tumble dryers are designed with fewer moving parts, so that you’ll face fewer maintenance

problems and less wear and tear. We make it even easier with a large, easy-to-clean lint compartment

and a heavy-duty door hinge designed to withstand heavy usage.

OVER-DRY

PREVENTION

TECHNOLOGY (OPT)

Reduce linen, labor and utility

costs with the precise drying

performance of OPT.

UNMATCHED

RELIABILITY

Quality construction for reliable

performance that is backed with a

3-year warranty.

PRACTICAL INGENUITY

The Combustion Auto Response

Equipped (C.A.R.E.) system

alerts you to abnormally high

temperatures in the cylinder and

automatically sprays water in the

cylinder to cool it down if necessary.

REVERSING CYLINDER

OPTION

Prevents tangling and ensures

even drying for easy removal

of loads.

EASY MAINTENANCE

Large, easy to clean lint

compartment simplifies

clean-up.

FASTER DRYING

High-performance heater box

ignites instantly, increases

energy efficiency and reduces

drying times.

UNCOMPLICATED

Fewer moving parts means easier

maintenance and less wear.

ON PREMISES TUMBLE DRYER SPECIFICATIONS

Tumble dryer models are made to suit a variety of electrical service characteristics. See your Speed Queen distributor for specifications. For further details on installation, refer to Installation, Operation

and Maintenance instructions supplied with the tumble dryer. Amperage ratings available in Installation Manual. For the most accurate information, the installation guide should be used for all design

and construction purposes. Due to continuous product improvements, design and specifications subject to change without notice. The quality management system of Alliance Laundry Systems’ Ripon

facility has been registered to ISO 9001:2000.

Printed in the U.S.A.

speedqueen.com

Capacity 50 lb 75 lb

Width 38 5/8” 38 5/8”

Depth 48 1/4” 54 1/4”

Height Gas and Electric

Steam

76 5/8”

80”

76 5/8”

80”

Cylinder Diameter 37” 37”

Cylinder Depth 30” 36”

Cylinder Volume 18.6 cu. ft. 22.4 cu. ft.

Door Opening Size 26 7/8” 26 7/8”

Energy Data Gas Models - Per Pocket

Steam Models - 100 psi

Electric Models

130,000 Btu/hr

178,000 Btu/hr

30 kW

165,000 Btu/hr

210,000 Btu/hr

30 kW

Gas Connections 1/2” NPT 1/2” NPT

Plumbing Connections - Steam 3/4” NPT 3/4” NPT

Air Outlet 8” 8”

Motor - HP Fan 1/3 Rev

1/2 Non Rev

1/3 Rev

3/4 Non Rev

Cylinder 1/3 Rev

1/3 Non Rev

1/3 Rev

1/3 Non Rev

Airflow Gas/Steam

Electric

750 cfm

920 cfm

750 cfm

Net Weight Gas/Steam

Electric

545 lb

615 lb

Electrical Specs Gas and Steam:

120/60/1

200-208/240/60/1

200-208/240/60/3

460-480/60/3

Amps - Non Rev/Rev

9.3/12

5.1/6.5

2.8/4.0

1.4/1.9

Amps - Non Rev/Rev

13.8/13

7.6/7

3.8/4.3

1.9/2.1

Electric:

200-208/60/3

240/60/3

480/60/3

Amps - Non Rev/Rev

89/88

79/78

38/38

Amps - Non Rev/Rev

89/88

79/78

38/38

Shipping Weight Gas/Steam

Electric

602 lb

677 lb

Shipping Width 41 1/2” 41 1/2”

Shipping Depth 52 1/8” 56 1/2”

Shipping Height 81” 81”

Agency Approvals Gas

Electric/Steam

CSA, CE CSA, CE

CSA, CE
