Samsung M207x Series User manual

BASIC

User’s Guide

BASIC

User’s Guide

This guide provides information concerning the installation, basic operation

and troubleshooting on windows.

ADVANCED

This guide provides information about the installation, advanced configuration, operation

and troubleshooting on various OS environments.

Some features may not be available depending on models or countries.

Downloaded from www.vandenborre.be

1. Introduction

This chapter provides information you need to know before using the machine.

•Keybenefits 2

• Features by models 4

• Useful to know 9

• About this user’s guide 10

• Safety information 11

• Machine overview 16

• Control panel overview 20

• Turning on the machine 24

• Installing the driver locally 25

• Reinstalling the driver 26

Downloaded from www.vandenborre.be

Key benefits

Environmentally friendly

• To save toner and paper, this machine supports Eco feature (see "Eco

printing" on page 52).

• To save paper, you can print multiple pages on one single sheet of paper

(see "Using advanced print features" on page 212).

• To save paper, you can print on both sides of the paper (double-sided

printing) (Manual) (see "Using advanced print features" on page 212).

• To save electricity, this machine automatically conserves electricity by

substantially reducing power consumption when not in use.

• We recommend using recycled paper for saving energy.

Fast high resolution printing

• You can print with a resolution of up to 1,200 x 1,200 dpi effective output.

• Fast, on-demand printing.

- M207x series

▪For single-side printing, 20 ppm (A4) or 21 ppm (Letter).

- M2074 series

▪For single-side printing, 18 ppm (A4) or 19 ppm (Letter).

Convenience

• Easy Capture Manager allows you to easily edit and print whatever you

captured using the Print Screen key on the keyboard (see "Easy Capture

Manager" on page 243).

• Samsung Easy Document Creator is an application to help users scan,

compile, and save documents in multiple formats, including .epub format.

These documents can be shared via social networking sites or fax (see"Using

Samsung Easy Document Creator" on page 249)

Downloaded from www.vandenborre.be

Key benefits

• AnyWeb Print helps you screen-capture, preview, scrap, and print the

screen of Windows Internet Explorer more easily, than when you use the

ordinary program (see "Samsung AnyWeb Print" on page 244).

• Smart Update allows you to check for the latest software and install the

latest version during the printer driver installation process. This is available

only for Windows.

• If you have Internet access, you can get help, support application, machine

drivers, manuals, and order information from the Samsung website,

www.samsung.com > find your product > Support or Downloads.

Wide range of functionality and application support

• Supports various paper sizes (see "Print media specifications" on page 104).

• Print watermark: You can customize your documents with words, such as

“Confidential” (see "Using advanced print features" on page 212).

• Print posters: The text and pictures of each page of your document are

magnified and printed across the multiple sheets of paper and can then be

taped together to form a poster (see "Using advanced print features" on

page 212).

• You can print in various operating systems (see "System requirements" on

page 107).

• Your machine is equipped with a USB interface and/or a network interface.

AirPrint

• AirPrint allows you to wirelessly print directly from iPhone, iPad and iPod

touch running iOS 4.2 or later.

Supports various wireless network setting method

• Using the WPS (Wi-Fi Protected Setup™) button

- You can easily connect to a wireless network using the WPS button on the

machine and the access point (a wireless router).

• Using the USB cable or a network cable

- You can connect and set various wireless network settings using a USB

cable or a network cable.

• Using the Wi-Fi Direct

- You can conveniently print from your mobile device using the Wi-Fi or Wi-

Fi Direct feature.

See "Introducing wireless set up methods" on page 145.

Downloaded from www.vandenborre.be

Features by models

Some features and optional goods may not be available depending on model or country.

Operating System

(●: Included, Blank: Not available)

Software

Operating System M207x series

M207xW series

M207xF series

M207xFW series

M207xFH series

M207xHW series

Windows ● ●

Mac ● ●

Linux ● ●

Software M207x series

M207xW series

M207xF series

M207xFW series

M207xFH series

M207xHW series

SPL printer driver ● ●

PCL printer driver

PS printer driver

Downloaded from www.vandenborre.be

Features by models

(●: Included, Blank: Not available)

XPS printer drivera● ●

Direct Printing Utility

Samsung Easy Printer Manager Scan to PC settings ● ●

Fax to PC settings ●

Device Settings ● ●

Samsung Easy Document Creator ● ●

Samsung Printer Status ● ●

AnyWeb Print ● ●

SyncThru™ Web Service ●

(M207xW series only)

●

(M207xFW series only)

SyncThru Admin Web Service ●

(M207xW series only)

●

(M207xFW series only)

Easy Eco Driver ● ●

Fax Samsung Network PC Fax ●

a. For XPS driver, it is only supported for Windows through the Samsung website (www.samsung.com)

Software M207x series

M207xW series

M207xF series

M207xFW series

M207xFH series

M207xHW series

Downloaded from www.vandenborre.be

Features by models

Variety feature

Features M207x series

M207xW series

M207xF series

M207xFW series

M207xFH series

M207xHW series

Hi-Speed USB 2.0 ● ●

Network Interface Ethernet 10/100 Base TX wired LAN ●

(M207xFW series /M207xHW series only)

Network Interface 802.11b/g/n wireless LANa●

(M207xW series only)

●

(M207xFW series /M207xHW series only)

NFC printing/scanning ●

(M207xW series only)

●

(M207xFW series /M207xHW series only)

Eco printing (Control panel) ● ●

Duplex (2-sided) printing (Manual)b● ●

USB memory interface

Memory module

Mass Storage Device (HDD)

Duplex Automatic Document Feeder (DADF)

Automatic Document Feeder (ADF) ●

Downloaded from www.vandenborre.be

Features by models

Fax Multi-send ●

Delay send ●

Priority send ●

Duplex send

Secure receive ●

Duplex print

Send/ Receive forward - fax ●

Send/ Receive forward - email

Send/ Receive forward - server

Scan Scanning to email

Scanning to SMB server

Scanning to FTP server

Duplex scan

Scan to PC ● ●

Scan to WSD ●

(M207xW series only)

●

(M207xFW series only)

Features M207x series

M207xW series

M207xF series

M207xFW series

M207xFH series

M207xHW series

Downloaded from www.vandenborre.be

Features by models

(●: Included, Blank: Not available)

Copy ID card copying ● ●

Reduced or enlarged copying ● ●

Collation ● ●

Poster

Clone

Book

2-up/4-up ● ●

Adjust background ● ●

Margin shift

Edge erase

Gray enhance

Duplex copy

a. Depending on your country, wireless LAN card may not be available. For some counties, only 802.11 b/g can be applied. Contact your local Samsung dealer or the retailer where you

bought your machine.

b. Windows only.

Features M207x series

M207xW series

M207xF series

M207xFW series

M207xFH series

M207xHW series

Downloaded from www.vandenborre.be

Useful to know

The machine does not print.

•Open the print queue list and remove the document from the list

(see "Canceling a print job" on page 49).

•Remove the driver and install it again (see "Installing the driver

locally" on page 25).

•Select your machine as your default machine in your Windows

(see "Setting your machine as a default machine" on page 211).

Where can I purchase accessories or supplies?

•Inquire at a Samsung distributor or your retailer.

•Visit www.samsung.com/supplies. Select your country/region to

view product service information.

The status LED flashes or remains constantly on.

•Turn the product off and on again.

•Check the meanings of LED indications in this manual and

troubleshoot accordingly (see "Understanding the status LED"

on page 93).

A paper jam has occurred.

•Open and close the scan unit (see "Front view" on page 16).

•Check the instructions on removing jammed paper in this manual

and troubleshoot accordingly (see "Clearing paper jams" on

page 89).

Printouts are blurry.

•The toner level might be low or uneven. Shake the toner

cartridge (see "Redistributing toner" on page 69).

•Try a different print resolution setting (see "Opening printing

preferences" on page 50).

•Replace the toner cartridge (see "Toner cartridge" on page 71).

Where can I download the machine’s driver?

•You can get help, support application, machine drivers, manuals,

and order information from the Samsung website,

www.samsung.com > find your product > Support or

Downloads.

Downloaded from www.vandenborre.be
