Rheem 120 User manual

120, 208, 240,

277 and 480

voltages

Point-Of-UseElectric CommercialWater Heaters

Available in Sizes Ranging From 2-1/2 – 30 GallonTank-Type Models



1440 Watts thru 6000 Watts

Rheem-Ruud point-of-use electric commercial water heaters are designed to

provide hot water at the consumption point, eliminating costly temperature

loss in long piping runs.Well suited for a wide variety of applications, point-of-

use heaters are small enough for installation in limited spaces under coun-

ters, mop sinks, cabinets, or any remote area where modest quantities of hot

water are required.They are ideally suited for applications in retail stores,

public restrooms, office washrooms, kitchen and mop or bar sinks.

Construction Features:

•

Long life tank design –

proprietary steel formulation with a

unique coat of high temperature

porcelain enamel to maximize

corrosion resistance resulting in a

superior tank design. A patented

R-Tech anode rod provides

advanced technology; equalizing

aggressive water action while

prolonging the effective life of

the anode rod and in turn the

life of the tank.

•

Long life heating elements –

Our patented resistor elements

are designed with a specially

treated, double layer of magne-

sium oxide and copper to

resist corrosion.

•

Efficient design –

Rigid polyurethane foam insulation

provides superior insulating

qualities resulting in reduced

operating costs.

•

Optional wall mounting kit –

The wall mounting kit provides an

easy way to mount the unit off the

floor, out of the way for more use-

able floor space in a small area.

Each kit is designed to be used on

walls with 16" stud centers. All

necessary parts are included in

this easy to install kit. (Note:The

2-1/2 gallon model comes stan-

dard with a wall mounting kit.)

•

Automatic temperature

control –

A surface mounted thermostat

automatically cycles on and off to

maintain the water temperature at

a desired preset level.

•

Temperature limiting control –

Automatically and safely cuts off

the power in the unlikely event that

the water temperature exceeds

190°F.

•

Temperature and pressure

relief valve –

AGA/ASME rated and factory

installed.

•

Certifications and Ratings:

• Efficiency – these models meet or exceed thermal efficiency and standby

loss requirements of current ASHRAE standards. (Part of the Federally

mandated Energy Policy Act (EPact)). Also exceeds energy efficiency codes

of all states including California Energy Commission (CEC).

• Safety and construction – these products are design certified by

Underwriters Laboratories (UL) to meet UL standard 174 as electric storage

tank water heaters. All models are North Carolina Code compliant.

CERTIFIED FOR A 150 PSI MAXIMUM WORKING PRESSURE.

Continued on reverse.

Point-Of-Use continued.

COMMERCIAL

WATER HEATERS

Rheem Water Heating •101 Bell Road, Montgomery, Alabama 36117-4305 •www.rheem.com

Rheem Canada Ltd./Ltée,128 Barton Street West, Hamilton, Ontario L8N 3P3

PRINTED IN U.S.A 10/06 WP FORM NO. RR102CE-4 Rev. 9

In keeping with its policy of continuous progress and product improvement, Rheem-Ruud reserves the right to make changes without notice.

Recommended Specifications:

Water heater(s) shall be model ______________, manu-

factured by RHEEM-RUUD, having electrical input of

__________ kW and a recovery rate of _____________

GPH at a 100°F temperature rise.Water heater(s) shall

have a storage capacity of ________ gallons.Water

heater(s) shall have the UL seal of certification and be

factory equipped with an AGA/ASME rated temperature

and pressure relief valve.Tank(s) interior shall be coated

with a high temperature porcelain enamel and furnished

with an R-Tech resistored magnesium anode rod rigidly

supported.Water heater(s) shall meet or exceed the

energy factor requirements of ASHRAE.Tanks shall have

a working pressure rating of 150 psi, and shall be com-

pletely assembled.Water heater(s) shall be equipped

with a copper, resistored, “screw-in”type element.Tank

shall be insulated with rigid polyurethane foam

insulation.Water heater(s) shall be equipped with a

surface mounted thermostat with an integral, manual

reset, high limit control.Water heater(s) shall be covered

by a three year limited warranty against tank leaks.

Limited Warranty:

This product features a three year limited warranty

against tank leaks. Please refer to Commercial Warranty

Information brochure for complete warranty information.

DIAMETER

DIMENSIONAL INFORMATION (All dimensions shown in English and Metric)

TANK

APPROXIMATE

MODEL MIN MAX

CAPACITY ABCDESHIPPING WEIGHT

NUMBER WATTS WATTS

GALLONS LITERS

inches mm inches mm inches mm inches mm inches mm LBS. KGS.

EGSP2 1,440 1,500 2.5 914 356 9-3/4 248 -——-———— 18 8

EGSP6 1,500 6,000 6 23 15-1/8 384 15-3/4 400 12-5/8 321 11-5/8 295 4-1/4 108 41 19

EGSP10 1,500 6,000 10 38 22-7/8 581 15-3/4 400 20-3/8 518 19-3/8 492 4-1/4 108 53 24

EGSP15 1,500 6,000 15 57 24-1/4 616 17-3/4 451 21-7/8 556 19-3/8 492 4-5/8 117 65 29

EGSP20 1,500 6,000 19.9 75 25-1/8 638 19-3/4 502 22-5/8 575 19-3/8 492 5-1/8 130 76 34

EGSP30 1,500 6,000 30 114 30 762 21-3/4 533 23 584 23 584 2-3/4 70 115 52

ELECTRICAL CHARACTERISTICS

ELEMENT SINGLE PHASE OPERATION ONLY –AMPS

WATTAGE 120 V 208 V 240 V 277 V 480 V

1,440 12.0 NA NA NA NA

1,500 12.5 7.2 6.3 N/A N/A

2,000 16.7 9.6 8.3 7.2 4.2

2,500 20.8 12.0 10.4 NA NA

3,000 25.0 14.4 12.5 10.8 6.3

4,500 NA 21.6 18.8 16.2 9.4

6,000 NA 28.8 25.0 21.7 12.5

All models employ 1 heating element resulting in a 2-wire outlet

(single phase) electrical configuration.

RECOVERY CAPACITIES

Recovery in U.S. Gallons/Hr. (GPH) and Liters/Hr. (LPH)

at Various Temperature Rises

40°F 60°F80°F 100°F 120°F

ELEMENT (22°C) (33°C) (45°C) (56°C) (67°C)

WATTAGE GPH LPH GPH LPH GPH LPH GPH LPH GPH LPH

1,440 15 55 10 37 728 622 518

1,500

15 58 10 38 829 623 519

2,000

20 77 14 51 10 38 831 726

2,500 25 96 17 64 13 48 10 38 832

3,000

30 115 20 77 15 58 12 46 10 38

4,500 46 173 30 115 23 86 18 69 15 58

6,000

61 230 41 153 30 115 24 92 20 77

Water

Temperature

Ratings:

Thermostat

Type:

Surface Mounted

Minimum

Temperature:

110

°F (43.3°C)

Maximum

Temperature:

170

°F(76.7°C)

High Temperature

Limit:

190

°F(87.8°C)

MODELS:

EGSP6

EGSP10

EGSP15

EGSP20

EGSP30

Water

Connections

3/4" NPT

MODEL:

EGSP2

Water

Connections

1/2" NPT

3/4" T&P

HOT

WATER

OUTLET

COLD

WATER

INLET

NOTE: Basic model numbers are listed.When ordering, specify electrical input and kW to determine specific model number.

PRODUCT AVAILABILITY

ELEMENT SINGLE PHASE OPERATION ONLY

WATTAGE 120 V 208 V 240 V 277 V 480 V

1,440 Y** NA NA NA NA

1,500 Y Y Y** N/A N/A

2,000 Y Y Y Y Y

2,500 Y Y Y NA NA

3,000 Y Y Y Y Y

4,500 NA Y Y* Y* Y*

6,000 NA Y Y Y Y

*Not available in EGSP6 & EGSP10

**EGSP2 available only in these configurations

HOT WATER

CONNECTION COLD WATER

CONNECTION

3/4" T&P

3-1/2" (89mm)
