Qiewa Q3 Royal Wing User manual
Ansbo Industrial Co., Ltd
All Rights Reserved
Copyright C
電動滑板車Q3
Royal Wing ELECTRIC SCOOTER
Q3
使用說明書
User Manual
目錄
說明書包含重要的安全使用說明，首次使用前請務必仔細閱讀。
油門與煞車控制
功能圖 P17
P18
P19
P20
P21
P21
P22
P23
P24
P25
車體摺疊與展開說明
電量及速度顯示說明
行駛注意事項
如何行駛
安全行駛與注意事項
注意事項
日常維護與保養
不屬於保固範圍之條件
P4
P2
P2
P4
P5
P6
P7
P8
P10
P11
P12
P12
P14 P26
參數
SAFETY WARNINGS
Table of Contents
GENERAL WARNIN
ACCEPTABLE RIDING PRACTICES
AND CONDITIONS
BEFORE YOU BEGIN
KNOWING THE ELECTRIC SCOOTER
HOW TO RIDE
SPECIFICATIONS
SAFETY PRECAUTIONS
CHARGING
CLEANING
FOLDING AND UNFOLDING
KNOWING THE MONITOR
PROPER RIDING ATTIRE
THANK YOU FOR CHOOSING ELECTRIC SCOOTER!
Before operating the electric scooter, read this User's Guide
for the proper instruction on use and care of the scooter!
▲ Lithium batteries, like all rechargeable batteries, are recyclable and should be recycled
or disposed of according to state and local guidelines. They should never be disposed of
in normal household waste, and they should never be incinerated, as they might explode.
Contact your local government for disposal or recycling practices in your area.
▲ DO NOT CHARGE THE BATTERY OVER NIGHT. WHEN CHARGING THE BATTERY,
DO NOT LEAVE UNATTENDED FOR LONG PERIODS OF TIME.
▲ This product meets and complies with all Federal regulations.
▲ Before using this electric skate, familiarize yourself with how to operate, so that you
can keep the scooter in the best condition possible.
▲ The User's Guide can help you to learn how to safely drive this electric scooter.
▲ User's Guide has all the instruction and notes, the operator must read it carefully and
follow these instructions. If the operator fails to follow the instructions or violate the
warnings, our company won't be responsible for any related results.
WARNING: To prevent or shock hazards, do not expose this unit to rain or moisture.
THE AC MUST REMAIN EASILY ACCESSIBLE IN ORDER TO BE ABLE
TO DISCONNECT THE DEVICE IN CASE OF EMERGENCY.
The lighting flash and arrow
head with in the triangle is
warning sign alerting you
of dangerous voltage
inside the product
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK DO NOT REMOVE
COVER (OR BACK). NO USER SERVICIABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
CAUTION
The exclamation point
with in the triangle is a
warning sign alerting you
of important instructions
accompanying the product
RISK OF ELECTRIC SHOCK
DO NOT OPEN
1
This manual contains important information. For your child's safety, it is your
responsibility to review this information with your child and make sure that your child
understands all warnings, cautions, instructions and safety topics. We recommend that
you periodically review and reinforce the information in this manual with younger riders
and that you are required to inspect and maintain your child's kick scooter to insure their
safety.
- Scooter riding can be a hazardous activity.
- Scooters can and are intended to move and it is therefore possible to get into
dangerous situations and/or lose control and/or fall.
- If such things occur you can be seriously injured.
LIKE ANY OTHERMOVING PRODUCT, USING A KICK SCOOTER CAN BE A
DANGEROUSACTIVITY AND MAY RESULT IN INJURY OR DEATH EVEN WHEN
USEDWITH PROPER SAFETY PRECAUTIONS. USE AT YOUR OWN RISK AND
USECOMMON SENSE. .
AN IMPORTANT MESSAGE TO PARENTS:
Always wear safety equipment such as a helmet, knee pads and elbow pads.
Always wear a helmet when riding your Scooter and keep the chinstrap
securely buckled.
SAFETY WARNINGS
GENERAL WARNIN
★Please wear appropriate protective equipment to avoid injury to yourself
SPECIAL WARNING: MUST BE USED BY A PERSON OF MORE THAN 12 YEARS!
2
▲ Always wear safety equipment such as a helmet, knee pads and elbow pads. Always
wear a helmet when riding your Scooter and keep the chinstrap securely buckled.
▲ Always wear shoes.
▲ Ride on smooth, paved surfaces away from motor vehicles.
▲ Avoid sharp bumps, drainage grates and sudden surface changes. Scooter may
suddenly stop.
▲ Avoid streets and surfaces with water, sand, gravel, dirt, leaves and other debris. Wet
weather impairs traction, braking and visibility.
▲ Do not ride at night.
▲ Adults must assist children in the initial adjustment procedures to unfold scooter,
adjust handlebar and steering height and finally to fold scooter.
▲ Obey all local traffic and scooter laws and regulations.
▲ Watch out for pedestrians.
▲ Do not exceed 150 Kgs total weight on the Scooter.
▲ Do not allow children under age 12 to use the Scooter. All children and preteens
should ride with adult supervision at all times.
▲ Rider weight does not necessarily mean a child's size is appropriate to fit or maintain
control of the Scooter.
▲ The skill required to ride this product may be greater than that required to ride a
traditional scooter.
▲ A parent's decision to allow his or her child to ride this product should be based on the
child's maturity, skill and ability.
▲ Refer to the section on safety for additional warnings.
3
- Direct parental supervision is required. Scooters are meant to be used only in controlled
environments free of potential traffic hazards and not on public streets.
- Do not allow your child to ride a Kick Scooter in any areas where vehicle traffic is
present. The child must maintain a hold on the handlebars at all times
- Never allow more than one child at a time to ride Scooter.
- Never use near steps, sloped driveways, hills, road ways, alleys or swimming pool
areas. Keep fingers and other body parts away from the product when folding or
unfolding. Adults must not allow children to assist in folding or unfolding the Kick Scooter.
- Do not ride a Kick Scooter in wet weather.
- Scooters are intended for use on solid, flat, clean and dry surfaces such as pavement
or level ground without loose debris such as rocks or gravel.
- Wet, slick or uneven and rough surfaces may impair traction and contribute to possible
accidents.
- Do not ride Kick Scooter in mud, ice, puddles or water.
- Avoid excessive speeds that can be associated with downhill rides.
- Never risk damaging surfaces such as carpet or flooring by use of a scooter indoors.
- Do not ride at night or when visibility is impaired.
- Always ensure child is wearing proper protective equipment such as an approved
safety helmet.
- A helmet may be legally required by local law or regulation in your area.
- A child should always wear shoes, never ride barefooted or in sandals and should keep
shoelaces tied and out of the way of the wheels.
ACCEPTABLE RIDING PRACTICES
AND CONDITIONS
PROPER RIDING ATTIRE
4
WARNING: ALWAYS INSPECT THE SCOOTER PRIOR TORIDING.
WARNING: CHECK LOCAL LAWS REGARDING KICK SCOOTERUSE. Check local laws and
regulations to see where and how you may use your scooter legally. In many states and local areas
scooter riders are required BY LAW to wear a helmet. Check local laws and regulations regarding
laws governing helmet use and Scooter operation in your area.
FAILURE TO USE COMMON SENSE AND HEED THE ABOVE WARNINGSFURTHER
INCREASES RISK OF SERIOUS INJURY.
USE AT YOUR OWN RISKAND WITH APPROPRIATE AND SERIOUS ATTENTION TO
SAFE OPERATION.
USE CAUTION.
- Properly inspecting and maintaining your scooter can reduce the risk of injury.
- Always inspect your scooter before riding and regularly maintain it.
Remove contents from box. Remove the foam separators that protect the components
from damage during shipping. Inspect the contents of the box for scratches in the paint
and dents that may have occurred during shipping. Because your kick scooter was
assembled and packed the factory, there should not be any problems, even if the box
has a few scars or dents.
BEFORE YOU BEGIN
5
Headlight Monitor
Accelerator
Light Switch
Battery Tank
Front Wheel
Foot Pedal
Folding Button
Fender and Brake
Motor
Rear Wheel
Brake
Charging Port
KNOWING THE ELECTRIC SCOOTER
6
ECO: Economical Speed, around 15km/h
NOR: Normal Speed, around 20km/h
MAX: Maximum Speed, around 25km/h
：Battery Indicators
KNOWING THE MONITOR
The five bars are indicator of the battery left.
F means the battery is fully charged.
E means there is ≦ 20% battery, you need to charge the battery. Under this status, the
scooter shall only run on the flat road, shall not go climbing, not move faster & not make
any abrupt turn or abrupt stop.
Power ON/OFF button.
Press + - to switch speed level.
(Economical speed,normal speed,
maximum speed).
Important: When there is only 1 bar left, you must get off the scooter imperatively and
stop using the scooter, and recharge the battery properly.
：Speed Indicator
ECO NOR MAX
7
Important note: Unless you hear a noise of click, otherwise it may not complete,
you need to try again.
FOLDING AND UNFOLDING
1. Press and hold the Folding Button (1)
2. Pull handlebars upward until steering tube is locked into place.
3. Unfolding complete when you hear a noise.
1
Unfolding
2
8
