Philips Fluorescent Lamps User manual

In theAsia Pacific region mains voltage fluctuation can

be a daily occurrence affecting the output of fluorescent

lamps and impeding ignition.The

ECONOMY

range of

electronic ballasts gives you back control over lighting

conditions.The range is designed to suit the spectrum

of rated mains voltages in the region – from 220-240V,

50 and/or 60Hz – and to handle mains voltage fluctuations

from 216-247V without affecting performance.Additionally,

the lamps will continue to operate well even if mains

voltage drops to 184V or rises to 264V.

For more information please contact

Philips Lighting Electronics

Asia Pacific Headquarters

Building 1,No. 889Yishan Road

Shanghai 200233,China

Tel: + 86 21 6485 5330

Fax:+ 86 21 6485 2213

E-mail: deborah[email protected]

excellent lighting begins with us

General performance

12 5 0 811 01E

03/2002

Printed in Hong Kong

www.lighting.philips.com

2002

EB-ECONOMY

Ballasts

for

fluorescent lamps

The

ECONOMY

is even designed to the same mounting

size as electromagnetic ballasts,allowing for easy removal of

electromagnetic ballasts,starter and capacitors and their

replacement with the more advanced

ECONOMY

electronic ballasts.When comfort, cost of installation and

operation,safety and reliability are key considerations,the

ECONOMY

is the answer.

The

ECONOMY

range of electronic ballasts is in a class

of its own where cost is a key consideration but comfort and

quality are no less important.

Using up to 20% less energy than electromagnetic ballasts,

Philips

ECONOMY

electronic ballasts equal bottom line

savings,which makes them the smart choice in situations

that require a lighting system to balance comfort and

confidence with cost-efficiency.

The versatile

ECONOMY

is flexible enough to be used

with‘

’,‘

’

and

lamps and,designed to the highest

specifications,the

ECONOMY

complies with

IEC

928

safety standards.Manufacture takes place in facilities certified

ISO

9001-compliant as a further assurance of safety and

reliability.

ISO

14001certification of the manufacturing process

gives customers the peace of mind that comes from knowing

the products they use are made in an environmentally

responsible way.

Lamp life is guaranteed by a crest factor of under 1.7 and

heating lamp electrodes during ignition.Even strong mains

voltage fluctuations cannot impede the comfortable flicker-

free operation of a lamp operating through an

ECONOMY

electric ballast.The robust construction of the

ECONOMY

including internal potting,also prevents interference from

moisture and dust.Lightweight, compact, cost-saving and

energy efficient, the Philips

ECONOMY

is an easy choice

to replace dated electromagnetic systems.

Benefits

* data subject to change

Energy saving calculation

Step 1 Determine traditional ‘TL’40W,52W System power

electromagnetic system

(

T12+ballast+starter)

Step 2 Determine new ‘TL’D 36W,36W System power

electronic system

(

T8+EB-E ballast)

Step 3 Determine average 4,000 hours

burning hours per year

(Typical office building)

Step 4 Determine cost US$0.10

per KWH

(Depending on local

supply condition)

Annual cost saving = (Step 1- Step 2) x Step 3 x Step 4

1000

Example:

Annual cost saving = (52-36)x 4000 x US$0.10*= US$6.40

1000 Savings per lamp

Product portfolio

Lamp Quantity of lamps

family Wattage on one ballast

18W,36W 1 or 2 lamps

PL-L 18W,36W 1 or 2 lamps

22W,32W 1 lamp

‘TL’D

‘TL’E
