Philips HQ5847/16 User manual
ENGLISH 4
DEUTSCH 11
FRANÇAIS 19
NEDERLANDS 27
ESPAÑOL 34
ITALIANO 42
PORTUGUÊS 49
TÜRKÇE 57
HQ5847,5846
3
Important
C◗Make sure the appliance and the cord do not
get wet.
◗Only use the cord supplied.
Charge indications
C◗Charging
As soon as you start charging the empty shaver,
the red light illuminates.When there is sufficient
power for 1 shave,the green light starts blinking.
As charging continues,more and more lights will
become green to indicate to what level the
batteries have been charged.
C◗Batteries fully charged
When the batteries have been fully charged,all
lights will become green.
C◗Remanining shaving capacity
The number of lights illuminated indicates
approximately how much power there is left in
the batteries:the more lights are illuminated,the
more charge is left.A fully charged shaver has a
cordless shaving time up to 70 minutes.
C◗Batteries running low
When the batteries are running low,the lower
pilot light turns red.When you have switched off
the shaver,the red light will blink for 4 seconds.
ENGLISH4
Charging
Recharge and keep the appliance at a
temperature between 5cC and 35cC.
The appliance is suitable for mains voltages
ranging from 100 to 240V.
You can also shave without charging by
connecting the shaver to the mains.
To extend the lifetime of the batteries,remove
the powerplug from the wall socket and pull the
appliance plug out of the shaver when the
batteries have been fully charged.
C1Put the appliance plug in the shaver.
2Put the powerplug in the wall socket.
Do not recharge the shaver in a closed pouch.
3When charging for the first time or after a
long period of disuse:leave the shaver to
charge continuously for 4 hours.
Charging normally takes approx.1 hour.
4Remove the powerplug from the socket
and pull the appliance plug out of the
shaver when the batteries have been fully
charged.
Shaving
1Switch the appliance on by sliding the
on/off button upwards.
ENGLISH 5
C2Move the shaving heads quickly over your
skin,making both straight and circular
movements.
Shaving on a dry face gives the best results.
Your skin may need 2 or 3 weeks to get
accustomed to the Philishave system.
3Switch the shaver off.
C4Put the protection cap on the shaver to
prevent damage.
Replace the shaving heads (type HQ5 Reflex
Action) every 2 years for optimal shaving results.
Trimming
For grooming sideburns and moustache.
C1Open the trimmer by pushing the slide
upwards.
The trimmer can be activated while the motor is
running.
Cleaning
◗Regular cleaning guarantees better shaving
performance.
C◗For easy and optimal cleaning,the Philishave
Action Clean (shaving head cleaner,type
HQ100) is available.Ask your Philishave dealer
for information.
ENGLISH6
You can also clean the shaver in the following
way:
Every week:shaving unit
1Switch the shaver off,remove the
powerplug from the wall socket and pull
the appliance plug out of the shaver.
C2Clean the top of the appliance first,using
the brush supplied.
C3Press the release button and remove the
shaving unit.
C4Clean the inside of the shaving unit and the
hair chamber with the brush.
C5Put the shaving unit back onto the shaver.
Every two months:shaving heads
1Switch the shaver off,remove the
powerplug from the wall socket and pull
the appliance plug out of the shaver.
ENGLISH 7
2
1
C2Press the release button and remove the
shaving unit.
C3Turn the wheel anticlockwise and remove
the retaining frame.
C4Remove and clean the shaving heads
(cutters and guards) one by one.
Do not mix up the cutters and the guards.
This is essential since each cutter has been
ground with its corresponding guard for optimal
performance.If you accidentally mix the sets up,it
could take several weeks before optimal shaving
performance is restored.
C5Clean the cutter with the short-bristled
side of the brush.
Brush carefully in the direction of the arrow.
C6Brush the guard.
If necessary,you can clean the shaving unit with a
degreasing liquid (e.g.alcohol).Remember to
lubricate the central point of the guards with a
drop of sewing machine oil after cleaning.
ENGLISH8
2
1
2
1
C7Reassemble the shaving unit by replacing
the retaining frame.Press the wheel and
turn it clockwise.
8Put the shaving unit back onto the shaver.
Trimmer
1Switch the shaver off,remove the
powerplug from the wall socket and pull
the appliance plug out of the shaver.
2Clean the trimmer every time you have
used it.
3Lubricate the trimmer teeth with a drop
of sewing machine oil every six months.
Disposal of batteries
Remove the batteries when you discard the
shaver.Do not throw the batteries away with the
normal household waste,but hand them in at an
official collection point.You can also take the
batteries to a Philips Service Centre,which will
dispose of them in an environmentally safe way.
Only remove the batteries if they are completely
empty.
1Remove the powerplug from the socket
and pull the appliance plug out of the
shaver.
ENGLISH 9
2
1
C2Let the shaver run until it stops,undo the
screws and open the shaver.
3Remove the batteries.
Do not connect the shaver to the mains again
after the batteries have been removed.
Troubleshooting
◗Problem:The shaver does not work after the
on/off button has been slided upwards.
BSolution:Recharge the batteries.
If the shaver still does not work,see
'Guarantee & service'.
Guarantee & service
If you need information or if you have a
problem,please visit the PhilipsWeb site at
www.philips.com or contact the Philips Customer
Care Centre in your country (you will find its
phone number in the worldwide guarantee
leaflet).If there is no Customer Care Centre in
your country,turn to your local Philips dealer or
contact the Service Department of Philips
Domestic Appliances and Personal Care BV.
ENGLISH10
Wichtig
C◗Achten Sie darauf,dass das Gerät und das
Kabel nicht nass werden.
◗Verwenden Sie nur das mitgelieferte Kabel mit
Steckernetzgerät.
Ladeanzeige
C◗Aufladen
Sobald Sie beginnen,den entladenen
Rasierapparat aufzuladen,beginnt das rote Licht
zu leuchten.Wenn genügend elektrische Energie
für 1 Rasur gespeichert wurde,beginnt das grüne
Licht zu blinken.Mit fortschreitendem
Ladevorgang beginnen zur Anzeige des
Ladestandes der Akkus immer mehr Lampen grün
zu leuchten.
C◗Akkus voll aufgeladen
Wenn dieAkkus voll aufgeladen sind,leuchten alle
Lampen grün.
C◗Restkapazität
Die Anzahl der leuchtenden Lampen zeigt an,
wieviel Energie ungefähr noch in den Akkus
verbleibt.Je mehr Lichter,desto mehr Energie
verbleibt in den Akkus.Die netzunabhängige
Betriebsdauer des voll aufgeladenen
Rasierapparats beträgt bis zu 70 Minuten.
C◗Akkus nachladen
Wenn die Ladung derAkkus zur Neige geht,
DEUTSCH 11
leuchtet die unterste Kontroll-Lampe rot auf.Die
rote Kontroll-Lampe blinkt 4 Sekunden nach
Ausschalten des Geräts.
Aufladen
Laden Sie die Akkus bei einerTemperatur
zwischen 5cC und 35cC,und bewahren Sie das
Gerät auch in diesemTemperaturbereich auf.
Das Gerät eignet sich für Netzspannungen von
100 bis 240Volt.
Sie können sich auch bei leeren Akkus rasieren,
indem Sie den Rasierapparat an das Netz
anschließen.
Sie verlängern die Nutzungsdauer der Akkus
wenn Sie nach dem Aufladen der Akkus das
Steckernetzgerät aus der Steckdose und den
Gerätestecker aus dem Rasierer ziehen.
C1Stecken Sie den Gerätestecker in den
Rasierapparat.
2Stecken Sie das Steckernetzgerät in die
Steckdose.
Laden Sie den Rasierapparat nicht in der
geschlossenenTasche auf.
3Beim erstmaligen Laden,und wenn der
Rasierapparat für einen längeren Zeitraum
nicht benutzt wurde,beträgt die
Ladedauer 4 Stunden.
Normalerweise beträgt die Ladedauer ungefähr 1
Stunde.
DEUTSCH12
