Panasonic FZ-55 Series User manual

SSD Pack

Inserting/Removing the SSD Pack

You can replace the SSD Pack.

IMPORTANT

nBack up all the important data before removing the SSD Pack.

nIf you need to read the SSD Pack data on another computer for repair or any other purpose, set [Hard Disk Lock] to [Disabled] in the [Security]

menu of the Setup Utilitybefore removing the SSD Pack.

nCarefully remove/insert the SSD Pack since the SSD Pack is extremely sensitive to shock. Note that static electricity may affect some internal com-

ponents.

1. Turn off the computer.

Do not use sleep or hibernation.

Perform the following steps to turn off the computer.

1. Click (Start) - (Settings) - [Update & Security] - [Recovery].

2. Click [Restart now] under “Advanced startup”.

3. Click [Turn off your PC].

2. Disconnect the AC adaptor, remove the battery pack. ( Replacing the Battery Pack)

Remove the second battery pack. ( Replacing the Battery Pack)

3. Insert/Remove the SSD Pack.

To remove <SSD pack (FZ-VSDR55)>

1. While sliding the latch (A), lift the SSD Pack(B) and slide it out of the slot.

To remove <SSD Pack (FZ-VSD551)>

1. While sliding the latch (C), pullout the SSD Pack (D).

To insert <SSD pack (FZ-VSDR55)>

1. Insert the projection part (E) of the SSD pack into the (F) part, and attach it while lowering untilit clicks.

To insert <SSD Pack (FZ-VSD551)>

1. Slide the SSD Pack in parallel with the arrow direction until it click to the secured position.

4. Insert the Battery Pack ( Insert the Battery Pack).

IMPORTANT

nConfirm that the latch is surely locked so that the SSD Pack does not fall when you carry the computer.

nBe sure to attach the SSD Pack for use.

N O T E

nYou can erase the data before changing the SSD Pack ( Erasing Flash Memory Data).

nYou can check that the SSD Packisrecognized or not in the [Information Menu] of the Setup Utility. If the SSD Pack is not recognized, turn off the

computer and insert it again.
