Panasonic KX-HNP100 User manual

Installation Guide

Home Network System

Backup Battery

Model No. KX-HNP100

Thank you for purchasing a Panasonic product.

This document explains how to install the backup battery properly.

For details about how to use the system, refer to the User’s Guide

(page 12).

Please read this document before using the unit and save it for future

reference.

For assistance, please contact us at 1-800-272-7033 or visit our Web

site: www.panasonic.com/support for customers in the U.S.A. or

Puerto Rico.

Please register your product: www.panasonic.com/prodreg

In order to use this device:

RDownload the latest version of the [Home Network] app.

RUpdate your hub to the latest firmware version (version 5.00 or later).

For more information, refer to the User’s Guide (page 12).

Printed in China

Shinsei_HNP100_(en_us)_0420_ver.000.pdf 1 2015/04/20 11:39:45

Introduction

Accessory information ...............3

Other information .......................3

Important Information

About this system ......................4

For your safety ...........................4

Important safety instructions ......6

For best performance ................6

Other information .......................7

Setup

Part names and functions ..........8

LED indicator .............................8

Backup battery performance

(when using the supplied

battery) ......................................8

Setup overview ..........................9

Inserting the battery ...................9

Connections ...............................9

Registering the backup

battery ......................................10

Wireless communication

range .......................................11

Appendix

Features available when using the

[Home Network] app ................12

Accessing the User’s Guide ....12

Specifications ..........................13

FCC and other information ......14

Customer services ...................16

Warranty (For United States and

Puerto Rico) .............................17

Table of Contents

Shinsei_HNP100_(en_us)_0420_ver.000.pdf 2 2015/04/20 11:39:45

Accessory information

Supplied accessories

No. Accessory item/Part number Quantity

ARechargeable battery 1

Additional/replacement accessories

Please contact your nearest Panasonic dealer for sales information (page 16).

Accessory item Model no./Specifications

Rechargeable

battery

KX-PRA10EX*1

RTo order, please visit

www.panasonic.com/batterystore

Battery type:

–Lithium Ion (Li-Ion) type battery

*1 The replacement battery may have a different capacity from that of the

supplied battery.

Other information

RDesign and specifications are subject to change without notice.

RThe illustrations in these instructions may vary slightly from the actual product.

Trademarks

RiPhone and iPad are registered trademarks of Apple Inc.

RAndroid is a trademark of Google Inc.

RMicrosoft, Windows, and Internet Explorer are either registered trademarks or

trademarks of Microsoft Corporation in the United States and/or other countries.

RAll other trademarks identified herein are the property of their respective owners.

For assistance, please visit www.panasonic.com/support 3

Introduction

Shinsei_HNP100_(en_us)_0420_ver.000.pdf 3 2015/04/20 11:39:45

About this system

RThis system is an auxiliary system; it

is not designed to provide complete

protection from property loss.

Panasonic will not be held

responsible in the event that

property loss occurs while this

system is in operation.

RThe system’s wireless features are

subject to interference, therefore

functionality in all situations cannot

be guaranteed. Panasonic will not

be held responsible for injury or

damage to property that occurs in

the event of wireless communication

error or failure.

For your safety

To prevent severe injury and loss of life/

property, read this section carefully

before using the product to ensure

proper and safe operation of your

product.

WARNING

Power connection

RUse only the power source marked

on the product.

RUnplug the product from power

outlets if it emits smoke, an

abnormal smell, or makes an

unusual noise. These conditions can

cause fire or electric shock. Confirm

that smoke has stopped emitting

and contact us at

www.panasonic.com/contactinfo

RUnplug from power outlets and

never touch the inside of the product

if its casing has been broken open.

Danger of electric shock exists.

RNever touch the plug with wet

hands. Danger of electric shock

exists.

RDo not connect non-specified

devices.

RDo not leave the power cable

exposed outdoors.

Installation

RTo prevent the risk of fire or

electrical shock, do not expose the

product to rain or any type of

moisture.

RDo not place or use this product

near automatically controlled

devices such as automatic doors

and fire alarms. Radio waves

emitted from this product may cause

such devices to malfunction

resulting in an accident.

RDo not allow the AC adaptor to be

excessively pulled, bent or placed

under heavy objects.

Operating safeguards

RBefore opening the cover,

disconnect the product from the

power outlet and from the connected

device.

RBefore cleaning, disconnect the

product from the power outlet and

from the connected device, and then

remove the battery. Do not use

liquid or aerosol cleansers when

cleaning.

RDo not disassemble the product.

RNever put metal objects inside the

product. If metal objects enter the

product, turn off the circuit breaker

and contact an authorized service

center.

4For assistance, please visit www.panasonic.com/support

Important Information

Shinsei_HNP100_(en_us)_0420_ver.000.pdf 4 2015/04/20 11:39:45

Medical

RConsult the manufacturer of any

personal medical devices, such as

pacemakers or hearing aids, to

determine if they are adequately

shielded from external RF (radio

frequency) energy. DECT features

operate between 1.92 GHz and

1.93 GHz with a peak transmission

power of 115 mW.

RDo not use the product in health

care facilities if any regulations

posted in the area instruct you not to

do so. Hospitals or health care

facilities may be using equipment

that could be sensitive to external

RF energy.

Lithium Ion (Li-Ion) battery

RDo not open, puncture, crush, or

drop the battery. A damaged battery

must not be used. This can result in

the risk of fire, explosion,

overheating, and leaking of the

electrolyte.

RDo not touch the terminals and

with metal objects.

RRisk of explosion if battery is

replaced by an incorrect type.

Dispose of used battery according to

local regulations.

RIf any electrolyte should come into

contact with your hands or clothes,

wash it off thoroughly with water.

RIf any electrolyte should come into

contact with your eyes, never rub

your eyes. Rinse your eyes

thoroughly with water, and then

consult a doctor.

CAUTION

Installation and location

RNever install wiring during a lightning

storm.

RThe AC adaptor is used as the main

disconnect device. Ensure that the

AC outlet is installed near the

product and is easily accessible.

RTo avoid the risk of strangulation,

keep the product and the AC

adaptor cord at least 1 m (3 feet)

from a child’s crib and out of the

reach of small children.

Lithium Ion (Li-Ion) battery

RCharge the battery provided with or

identified for use with this product

only, in accordance with the

instructions and limitations specified

in this manual.

RInsert the battery correctly.

RDo not leave the battery in an

automobile exposed to direct

sunlight for a long period of time with

the doors and windows closed.

RRemove the battery if you do not

use the product for a long period of

time. Keep it in a cool, dark area.

RDo not replace a battery with wet

hands.

RStop using the battery immediately

and keep away from fire if it emits an

abnormal smell or leaks electrolyte.

Released electrolyte may cause fire

or burns.

RExercise care when handling the

batteries. Do not allow conductive

materials such as rings, bracelets, or

keys to touch the batteries,

otherwise a short circuit may cause

the batteries and/or the conductive

For assistance, please visit www.panasonic.com/support 5

Important Information

Shinsei_HNP100_(en_us)_0420_ver.000.pdf 5 2015/04/20 11:39:45

material to overheat and cause

burns.

RDo not put any conductive materials

such as coins or hairpins onto the

charge contacts. This can result in

the risk of overheating.

Important safety

instructions

When using your product, basic safety

precautions should always be followed

to reduce the risk of fire, electric shock,

and injury to persons, including the

following:

1. Do not use this product near water

for example, near a bathtub,

washbowl, kitchen sink, or laundry

tub, in a wet basement or near a

swimming pool.

2. Use only the batteries indicated in

this document. Do not dispose of

batteries in a fire. They may

explode. Check with local codes for

possible special disposal

instructions.

SAVE THESE INSTRUCTIONS

For best performance

Hub location/avoiding noise

The hub and other compatible

Panasonic devices use radio waves to

communicate with each other.

RFor maximum coverage and

noise-free communications, place

your hub:

– at a convenient, high, and central

location with no obstructions

between the product and hub in

an indoor environment.

– away from electronic appliances

such as TVs, radios, personal

computers, wireless devices, or

other phones.

– facing away from radio frequency

transmitters, such as external

antennas of mobile phone cell

stations. (Avoid putting the hub

on a bay window or near a

window.)

RIf the reception for a hub location is

not satisfactory, move the hub to

another location for better reception.

Environment

RKeep the product away from

electrical noise generating devices,

such as fluorescent lamps and

motors.

RThe product should be kept free

from excessive smoke, dust, high

temperature, and vibration.

RThe product should not be exposed

to direct sunlight.

RDo not place heavy objects on top of

the product.

RThe product should be kept away

from heat sources such as heaters,

kitchen stoves, etc. It should not be

placed in rooms where the

temperature is less than 5 °C (41 °F)

or greater than 40 °C (104 °F).

Damp basements should also be

avoided.

ROperating the product near electrical

appliances may cause interference.

Move away from the electrical

appliances.

6For assistance, please visit www.panasonic.com/support

Important Information

Shinsei_HNP100_(en_us)_0420_ver.000.pdf 6 2015/04/20 11:39:45

Other information

CAUTION: Risk of explosion if battery

is replaced by an incorrect type.

Dispose of used batteries according to

the instructions.

Routine care

RWipe the outer surface of the

product with a soft moist cloth.

RDo not use benzine, thinner, or any

abrasive powder.

Information on Disposal in other

Countries outside the European

Union

These symbols are only valid in the

European Union. If you wish to discard

these items, please contact your local

authorities or dealer and ask for the

correct method of disposal.

Note for the battery removal

procedure

Refer to “Inserting the battery” on

page 9.

Notice:

For assistance, please visit www.panasonic.com/support 7

Important Information

Shinsei_HNP100_(en_us)_0420_ver.000.pdf 7 2015/04/20 11:39:45

Part names and

functions

M N

Used to register the backup

battery to the hub.

LED indicator

Power supply plug

DC jack

LED indicator

You can use the LED indicator to

confirm the backup battery’s status.

Indicator Status

Green, lit Normal operation

(when charging is

fully complete)

Green,

blinking

Registration mode

(you pressed and

held MN)

Red, blinking

slowly

Backup battery is

not registered to a

hub

Red, blinking Backup battery is

out of range of the

hub*1

Amber, lit Battery charging

Amber,

blinking

Power failure

detected

Off Low battery

*1 The LED indicator does not

indicate sensor status if the

backup battery has not been

registered (page 10).

Note:

RWhen the battery operating time

seems to be shorter, even after I

fully charged the battery:

– Clean the battery ends ( , )

and the charge contacts with a

dry cloth and charge again.

– It is time to replace the battery.

Backup battery

performance (when

using the supplied

battery)

The backup battery can provide power

to your Home Network System devices

(one device per backup battery),

allowing your devices to continue to

operate in the event of a power failure.

Compatible

devices*1 Operating time

HUB

(KX-HNB600)

Approx. 1.5 hours

(standby, connected

to 4 cameras, not

connected to a

Wi-Fi network)

Indoor

Camera

(KX-HNC200)

Approx. 1.8 hours

(standby, night view

mode)

Outdoor

Camera

(KX-HNC600)

Approx. 1.6 hours

(standby, night view

mode)

Indoor Siren

(KX-HNS105)

Approx. 8 hours

(standby)

8For assistance, please visit www.panasonic.com/support

Setup

Shinsei_HNP100_(en_us)_0420_ver.000.pdf 8 2015/04/20 11:39:45

*1 The corresponding models are

subject to change without notice.

Setup overview

1Initial setup

Make sure you can access the

system using your mobile device.

For details, refer to the System

Setup Guide included with your

hub.

2Insert the battery

The battery will supply power to

the connected device in the event

of a power failure.

3Connections

Connect the backup battery to the

power outlet and to the device it

will supply power to.

4Registration

Required only if the backup battery

was purchased separately (i.e.,

not as part of a bundle).

5Confirm the usage area

Read the information in this

document to confirm that the

desired usage area is suitable to

proper operation.

Inserting the battery

RUSE ONLY the specified battery.

RWipe the battery ends ( , ) with

a dry cloth.

RAvoid touching the battery ends ( ,

) or the unit contacts.

1Press the notch on the battery

cover firmly.

2Slide it in the direction of the arrow.

3Insert the battery.

4Close the battery cover.

Connections

Insert the power supply plug firmly

into the DC jack of the compatible

device.

Connect the AC adaptor plug to

the backup battery.

For assistance, please visit www.panasonic.com/support 9

Setup

Shinsei_HNP100_(en_us)_0420_ver.000.pdf 9 2015/04/20 11:39:45

Secure the AC adaptor cord by

wrapping it around the hook.

Connect the AC adaptor to the

power outlet.

Note:

RUse only the supplied Panasonic AC

adaptor PNLV236.

RIt takes about ten hours to fully

charge the battery.

RThe LED indicator lights in amber

while the battery is charging. When

charging is complete, the LED

indicator lights in green (page 8).

Note about power

connections

AC adaptor connection

RThe AC adaptor must remain

connected at all times. (It is normal

for the adaptor to feel warm during

use.)

RThe AC adaptor should be

connected to a vertically oriented or

floor-mounted AC outlet. Do not

connect the AC adaptor to a

ceiling-mounted AC outlet, as the

weight of the adaptor may cause it

to become disconnected.

Registering the

backup battery

This procedure is not required for

devices that were included as part of

a bundle.

Before you can use the backup battery,

it must be registered to the hub.

If you purchased devices separately

(i.e., not as part of a bundle), you must

You can register each device by using

the registration buttons or the [Home

Network] app.

Using registration buttons

1Hub:

Press and hold M OTHER

DEVICEN until the LED indicator

blinks in green.

2Backup battery:

Press and hold MN until the

LED indicator blinks in green

(page 8).

RWhen registration is complete,

the hub sounds one long beep.

Note:

RTo cancel without registering the

backup battery, press MN on the

hub and on the backup battery again.

RIf registration fails, the hub sounds

several short beeps.
