Lightolier Lytespan 8215WH User manual

3 1/4"

1 9/16"

1 13/16"

5 7/16"

4 13/16"

3 9/16"

CONE 16 WITH LOW PROFILE ADAPTER

CONE 16 WITH HINGED ADAPTER

Lytespan®Track Li htin System 8215WH

Pa e 1 of 2 PAR-TechTMCone 16 Shade

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Li htolier a Genlyte Thomas Company www.li htolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the ri ht to chan e details of desi n, materials and ﬁnish.

Features

1. Shade Attachment: Zinc plated and painted C.R. steel. Bayonet ﬁttin .

2. Shade: Sin le piece die-cast aluminum.

3. Mountin Groove: For accessory holder.

4. Color Accent Rin : Silicone rubber. (Removable)

5. Perimeter Ventin

Options & Accessories

2” Beam Smoother and Beam Elon ator. All require Accessory Holder 8581. See

Li htolier Speciﬁcation Sheets, AF2LF and AF2AS.

Do not use with AL2HC louver.

Finish

All painted ﬁnishes baked enamel.

Labels

UL; I.B.E.W.

8215WH

8215BK

Catalo No. Finishes Mountin Lamps

8215WH Matte White All Lytespan Track Systems 75W PAR16 (Tun sten-Halo en)

8215BK Matte Black (60W Max. with Accessories)

Orderin Information

Lytespan®Track Li htin System 8215WH

Pa e 2 of 2 PAR-TechTMCone 16 Shade

Li htolier a Genlyte Thomas Company www.li htolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the ri ht to chan e details of desi n, materials and ﬁnish.

Job Information Type:

Li htin Data

1,300 2,000

60W PAR16

NFL (Halogen) 30°

3' 144 1.6' 1.6'

5' 52 2.7' 2.7'

7' 27 3.6' 3.8'

9' 16 4.8' 4.8'

3' 1.7' 94 2.2' 1.0'

5' 2.9' 34 3.7' 3.1'

7' 4.0' 17 5.1' 4.3'

9' 5.2' 10 6.6' 5.6'

2' 2.0' 115 2.3' 1.5'

3' 3.0' 51 3.5' 2.3'

4' 4.0' 29 4.6' 3.0'

5' 5.0' 18 5.8' 3.8'

1' 1.7' 163 2.7' 1.1'

2' 3.5' 41 5.5' 2.1'

3' 5.2' 18 6.2' 3.2'

4' 6.9' 10 10.8' 4.3'

6' 139 1.0' 1.0'

8' 78 1.4' 1.4'

10' 50 1.7' 1.7'

12' 35 2.1' 2.1'

5' 2.9' 130 1.2' 1.0'

7' 4.0' 65 1.6' 1.4'

9' 5.2' 40 2.1' 1.8'

11' 8.4' 27 2.8' 2.2'

3' 3.0' 196 1.1' 0.7'

5' 5.0' 71 1.6' 1.2'

7' 7.0' 36 2.5' 1.7'

9' 9.0' 22 3.2' 2.2'

2' 3.5' 156 1.4' 0.7'

3' 5.2' 69 2.1' 1.0'

4' 6.9' 39 2.9' 1.4'

5' 8.7' 25 3.6' 1.7'

5,000 2,000

60W PAR16

NSP (Halogen) 10°

7' 153 1.2' 1.2'

10' 75 1.7' 1.7'

13' 44 2.3' 2.3'

16' 29 2.8' 2.8'

6' 3.5' 135 1.4' 1.2'

9' 5.2' 60 2.1' 1.8'

12' 6.9' 34 2.8' 2.4'

13' 8.7' 22 3.5' 3.0'

4' 4.0' 166 1.4' 1.0'

6' 6.0' 74 2.1' 1.5'

9' 9.0' 41 2.8' 2.0'

10' 10.0' 27 3.5' 2.5'

2' 3.5' 234 1.4' 0.7'

3' 5.2' 104 2.1' 1.0'

4' 6.9' 59 2.9' 1.4'

5' 8.7' 38 3.6' 1.7'

7,500 2,000

75W PAR16

(Halogen) 10°

DFC L W DC FC L W DC FC L W DC FC L W

50% Max. CP C.P. Candelas Life-Hrs

4' 119 2.1' 2.1'

6' 53 3.2' 3.2'

8' 30 4.3' 4.3'

10' 19 5.4' 5.4'

3' 1.7' 137 2.2' 1.9'

5' 2.9' 49 3.7' 3.1'

7' 4.0' 25 5.1' 4.3'

9' 5.2' 15 6.6' 5.6'

3' 3.0' 75 3.5' 2.3'

4' 4.0' 42 4.6' 3.0'

5' 5.0' 27 5.8' 5.8'

6' 6.0' 19 6.9' 4.5'

1' 1.7' 238 2.7' 1.1'

2' 3.5' 59 5.5' 2.1'

3' 5.2' 26 8.2' 3.2'

4' 6.9' 15 10.9' 4.3'

1,900 2,000

75W PAR16

NFL (Halogen) 30°

Beam Spread Beam Center Rated

DFCL

LAMP 0˚ AIMING ANGLE A=30˚ AIMING ANGLE A=45˚ AIMING ANGLE A=60˚ AIMING ANGLE

Aimin An le 0˚ 30˚, 45˚ or 60˚ Horizontal 30˚, 45˚ or 60˚ Vertical

LBeam Length

WBeam Width

CDistance to center beam

DDistance

AAiming Angle

FC Footcandles

Land Ware the outer points where the candle

power drops to 50% of the maximum. FC are the

initial footcandles at the center of the beam.
