Konica Minolta Bizhub C3100i User manual

bizhub C3100i

ORIGINAL INSTRUCTIONS

SETUP GUIDE

SUSTAINABLE AND ALWAYS UP-TO-DATE!

Our pool of digital resources allows you to make your operations more sustainable and

ecient. Access all latest materials and training resources around your system whilst

contributing to a more sustainable environment. No need for extensive search and without

having to print anything on paper.

Latest information at the click of a button

Download Center

Download printer drivers, utilities, user guides etc. all from one place —

with the assurance that it is the most up-to-date information.

Visit: https://konicaminolta.eu/download-centre

Step-by-step guidance for your system

iTraining

iTraining provides an online product introduction that uses clear video

sequences with detailed explanations of all the important functions of your

system. This step-by-step guidance makes getting to know your system

easy.

Visit: https://itraining.konicaminolta.eu

DIGITAL RESOURCES HUB

bizhub C3100i 1-1

1 Setup Guide

NOTICE

Please read the Safety information before setting up this machine.

1. Check the items included in the package.

-Main unit

-Power cord

2. Pull out the tapes.

1Remove all transport securing tapes from the system.

2Open the right side cover.

3Pull out the four tapes.

4Close the right side cover.

1-2 bizhub C3100i

3. Load the paper into the tray.

1Supporting the paper tray with both hands, pull it out completely.

2Move the paper guides to the position to fit the paper size.

3Place the side you want to print on facing up, and load the paper with its leading edge aligned with the

interior end of the tray.

NOTICE

Do not load an excessive number of sheets such that the top of the stack is higher than the

mark.

If paper is curled, flatten it before loading it.

4Insert the paper tray into the machine main unit, and press it in slowly until it stops.

bizhub C3100i 1-3

4. When using with a wired LAN or USB, connect the cable.

If you want to make a wireless LAN connection, proceed to step 5.

Connecting to a Wired Network

Connecting to a Computer With USB

1-4 bizhub C3100i

5. Turning on the machine.

1Connect the power cord to this machine and an outlet.

2Press the (Power Supply / Power Saver) button.

bizhub C3100i 1-5

6. Setting up initial settings of the machine.

1Press the + or , button to select a language, then press the button.

2Press the button.

3You can change the machine administrator's password for Internet Services.

%The machine administrator's default password is the 13-digit serial number indicated on the back

of the machine. Follow the on-screen instructions to enter the current password (serial number), a

new password containing at least 4 digits, and the same new password again.

%You can also select [Skip] with the + or , button and change the password later. If you select [Skip],

the machine administrator's password can only be changed from the Internet Services. For details

on Internet Services, refer to the [User's Guide].

4Press the button.

7. When using with a wireless LAN, make the following settings.

This section describes how to connect using WPS (push button method).

1Hold down the WPS key on the Control Panel.

2Follow the on-screen instructions to press the WPS button attached to the wireless LAN access point

within 2 minutes.

Tips

When connection to an access point or wireless router is complete, the machine will restart automatically.

For details, refer to the [User's Guide].

Serial No. : XXXXXXXXXXXXX

1-6 bizhub C3100i

8. Install the software.

Windows

1Extract [Printer Software] after downloading to the computer, and double-click on "Launcher.exe" in

the generated folder.

2Click on [Quick Setup].

3Follow the on-screen instructions to complete the setup.

Tips

If you want to select and install only the software you need, select the desired software from [Custom Instal-

lation]. For details, refer to the [User's Guide].
