Ingersoll-Rand 2190Ti User manual

04584900

Edition 5

January 2014

Save These Instructions

Product Information

EN Product Information

Especicaciones del producto

Spécications du produit

Speciche prodotto

Technische Produktdaten

Productspecicaties

Produktspecikationer

Produktspesikasjoner

Tuote-erittely

Especicações do Produto

Προδιαγραφέ προϊόντο

Specikacije izdelka

Špecikácie produktu

Specikace výrobku

Toote spetsikatsioon

A termék jellemzői

Gaminio techniniai duomenys

Ierices specikacijas

Informacje o Produkcie

Технические характеристики изделия

RU ZH JA

󲨓󳙿 󲊸󲌯

Информация за Продукта

Informaţii Privind Produsul

Podaci o proizvodu

Air Impact Wrench

Models 2190Ti, 2190Ti-6 and 2190DTi-6

04584900_ed5 EN-1

Product Safety Information

Intended Use:

These Air Impact Wrenches are designed to remove and install threaded fasteners.

For additional information refer to Product Safety Information Manual Form 04580916.

Manuals can be downloaded from ingersollrandproducts.com

Power Management System

For models that include a power management system, the system allows operator

reduction of maximum output power.

To adjust the power, rotate the Power Regulator to the desired level indicator.

The power level indicators are for reference and DO NOT indicate a specic power. The

power output can be further reduced in forward or reverse by using the variable throttle.

Product Specications

Model(s) Style Drive Impacts

per min.

Recommended Torque

Range

ft-lb (Nm)

Type Size Forward Reverse

2190Ti Grip Square 1” 875 150-1200

(204-1627)

150-1200

(204-1627)

2190Ti-6 Grip Square

extended 1”x6” 875 150-1200

(204-1627)

150-1200

(204-1627)

2190DTi-6 D Square

extended 1”x6” 875 150-1200

(204-1627)

150-1200

(204-1627)

Model(s)

Sound Level dB(A)

(ISO15744)

Vibration (m/s)

(ISO28927)

† Pressure (Lp) ‡ Power (Lw) Level *K

2190Ti 103.8 116.8 10.4 1.5

2190Ti-6 103.8 116.8 12.7 2.9

2190DTi-6 103.8 116.8 8.7 2.1

† KpA = 3dB measurement uncertainty

‡ KwA = 3dB measurement uncertainty

* K = Vibration measurement uncertainty

WARNING

Sound and vibration values were measured in compliance with internationally recognized

test standards. The exposure to the user in a specic tool application may vary from these

results. Therefore, on site measurements should be used to determine the hazard level in

that specic application.

EN-2 04584900_ed5

Installation and Lubrication

Size air supply line to ensure tool’s maximum operating pressure (PMAX) at tool inlet. Drain

condensate from valve(s) at low point(s) of piping, air lter and compressor tank daily. Install

a properly sized Safety Air Fuse upstream of hose and use an anti-whip device across any

hose coupling without internal shut-o, to prevent hose whipping if a hose fails or coupling

disconnects. See drawing 47132600 and table on page 2. Maintenance frequency is shown in a

circular arrow and dened as h=hours, d=days, and m=months of actual use. Items identied as:

1. Air lter 7. Coupling

2. Regulator 8. Safety Air Fuse

3. Lubricator 9. Oil

4. Emergency shut-o valve 10. Grease - during assembly

5. Hose diameter 11. Grease - through tting

6. Thread size

Parts and Maintenance

When the life of the tool has expired, it is recommended that the tool be disassembled,

degreased and parts be separated by material so that they can be recycled.

Original instructions are in English. Other languages are a translation of the original instructions.

Tool repair and maintenance should only be carried out by an authorized Service Center.

Refer all communications to the nearest Ingersoll Rand Oce or Distributor.
