c) Get correct sensor for the wheel, pass band through the two mounting hole
on the lower part of the sensor.
d) Wrap the band (with sensor) around the wheel base, insert band end into the
band clamp, and then use a socket wrench to advance the worm-gear until
the band is slightly pressing the wheel base.
e) Adjust band to the lowest areas of the drop center well on the wheel. Move
sensor to a position behind (but not touching) the valve. Make sure the sensor
is resting on a flat surface.
f) Using torque wrench tighten band to 30 inch pounds (4 N-m). The sensor
should be pulled down tightly against the wheel base and should not be
moveable.
g) Cut off excessive band (left about 1 inch). Mount tire on wheel, balance
wheel, and mount wheel back on car.
h) After sensor installation, turn on vehicle power (but do not start the car).
Inflate the tires to proper pressure. Observe that the display shows the
pressure and temperature one at a time for all tires. Pressing the control
button on the Display shows individual tire pressure and temperature.
Operation
After installation, the system operates automatically and continuously. When
vehicle power is turned on, the display will show the current tire pressure and
temperature one-by-one from tire No.1 to No. 4. The display then turns off and
only the status light remains lit. A green status light indicates normal pressure
and temperature for all tires, otherwise the status light turns red (low tire
pressure) or yellow (other warnings) and the corresponding tire indicator(s) and
the warning icon(s) are illuminated.
Warnings
Upon detection of abnormal tire pressure and/or temperature, the system will
sound an 8-second alarm and display the warnings.
FCC Compliance
This equipment has been tested and found to comply with the limits for a class
B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
