Harman JBL PROFESSIONAL EON ONE MK2 User manual

QUICKSTART GUIDE

BATTERY POWERED | ONE-HAND CARRY | BLUETOOTH AUDIO | LEGENDARY JBL SOUND

2. POWER ON THE UNIT

1. Connect the power cord to the

Power Receptacle (M).

2. Press the Power Button [G] for .5 of a

second to engage power.

Battery

and Speaker

Battery with

Speaker and

Spacer

3. PLUG IN THE INPUTS

1. Turn the Channel Volumes (E) all the way

to the left before connecting any inputs.

2. Connect your devices to the Input Jacks

[J] (K) (L] .

321.07

5. SET UP THE CHANNELS

1. Select the channel you wish to edit.

Turn the gain knob up until you reach the

desired volume.

2. Slowly turn the Main /Menu Encoder (C)

to the right until the desired volume

is reached.

4. EDIT A CHANNEL

1. Press the knob of the channel (E) you

wish to edit

2. You can now edit Bass, Mid, Treble and

Reverb for that respective channel.

3. The CH LED (F) above the respective

channel will light

4. Hold down the BACK button (B) for 2s

to return to mix mode.

This device supports Bluetooth audio

streaming.

To connect your device:

1. Turn on Bluetooth on your source device.

2. Use LCD Display [A] to trigger BT pairing.

3. Find EON1MK2 on your device and select

Bluetooth.

6. PAIR

®AUDIO

7. DOWNLOAD JBL PRO

CONNECT APP FROM APP

STORE/GOOGLE PLAY

It is recommended you ensure your

device is running the current firmware

through the application.

1. LISTENING

CONFIGURATIONS

Battery should

always be on bottom

JH IG

Power

Button

LCD Display

Multifunction

CH LED

Multifunction

CH Volume

USB

Ports

Limit LED

Main/Menu Encoder

Back

Button

XLR Male

Loop Thru

6.35mm Jack

3.5mm Jack

3 combo XLR/TRS

B D

For complete documentation, visit

http://www.jblpro.com/eononeMK2

EON ONE MK2 Quickstart Guide – 08/2021

Pour la version française de ce document, veuillez visiter le site www.jblpro.com/eononeMK2

Die deutsche Version dieses Dokuments finden Sie unter www.jblpro.com/eononeMK2

Para la versión en español de este documento, por favor visite www.jblpro.com/eononeMK2

Para a versão em português deste documento, visite www.jblpro.com/eononeMK2

Per la versione italiana di questo documento, visitare www.jblpro.com/eononeMK2

이 문서의 한국어 버전은 www.jblpro.com/eononeMK2 를 방문하십시오

有關本文檔的中文版，請訪問 www.jblpro.com/eononeMK2

Power Inlet
