FiberPatrol FP1150 Series User manual

Guide

FiberPatrol®

Ranging Fiber Optic Fence Protection Sensor

FPDA0802-402, Rev A

March 18, 2020

Product

FP1150 Series

Page 2 FiberPatrol Site Planning & Installation Guide

FiberPatrol

FPDA0802-402, Rev A

March 18, 2020

Website: www.senstar.com

FiberPatrol, Senstar and the Senstar logo are registered trademarks, and Silver Network is a trademark of Senstar Corporation.

Product names and Company names included in this document are used only for identification purposes and are the property

The information provided in this guide has been prepared by Senstar Corporation to the best of its ability. Senstar Corporation is

not responsible for any damage or accidents that may occur due to errors or omissions in this guide. Senstar Corporation is not

liable for any damages, or incidental consequences, arising from the use of, or the inability to use, the software and equipment

described in this guide. Senstar Corporation is not responsible for any damages, or incidental consequences, that may occur

due to information about items of equipment or components manufactured by other companies. Features and specifications are

subject to change without notice.

The figures included in this document are for illustration purposes only, and may differ from the actual equipment.

Compliance

The use of shielded cables is required for compliance.

USA: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device

may not cause harmful interference, and (2) this device must accept any interference received, including any interference that

may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the

FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to

correct the interference at his own expense.

Any changes or modifications to the software or equipment that are not expressly approved by Senstar Corporation void the

manufacturer’s warranty, and could void the user’s authority to operate the equipment.

Europe:

Conforms to EMC directive 2014/30/EU

Safety: EN 60950-1:2006 + A2:2013

Service statement - We ensure that our products are correctly applied to achieve the maximum benefits for the end-user. We

work hand-in-hand with our customers and remain accessible through all stages of a project - from concept to deployment to

long-term support. We provide design assistance, site surveys, installation support, comprehensive documentation, training,

post-installation annual calibration and maintenance visits, electronics and software extended warranty, rapid factory repair

service and on-call/emergency service.

FiberPatrol Site Planning & Installation Guide Page 3

Table of contents

1 System description - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -9

Principles of operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9

FiberPatrol sensor system details - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9

FP1150 configurations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 10

Alarm reporting - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 11

FP1150 Series Cable length requirements - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 11

FiberPatrol components - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 12

Sensor unit - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 12

Fiber connection module - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 12

Outdoor splice enclosure - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 13

End module - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 14

Sensor cable/non-detecting lead cable - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 14

Cable ties - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 15

Sensitivity loops - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 15

Service loops - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 16

Isolation loops - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 16

Buried vault - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 16

2 Site planning - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -17

FiberPatrol configurations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 17

Loop configurations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 17

Split configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 19

Line configurations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 21

Extended lead configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 22

Site survey - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 23

Fences - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 23

Chain-link fences - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 23

Weld-mesh fences - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 24

Fence height considerations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 24

Climb-over deterrent hardware - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 24

Barbed wire - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 24

Razor ribbon/concertina - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 25

Gates - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 26

Gate bypasses - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 26

Protecting swinging gates with FiberPatrol - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 26

Page 4 FiberPatrol Site Planning & Installation Guide

Gate protection for periodically bypassed gates (independent zones) - - - - - - - - - - - - - - - - 27

Determining cable length requirements for gates - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 28

Using the cable management kit at the hinged side of protected swinging gates - - - - - - - - 28

Protecting masonry walls and buildings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -29

Selecting conduit for below ground bypasses - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -30

Solid wall conduit - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 30

Split wall conduit - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 31

Sensitivity loops for heavier gauge posts - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -31

Service loops - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 32

Isolation loops (optional) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 32

Cable bypasses for buildings and structures - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 33

Deploying the sensor cable - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -34

Sensor cable splices - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -34

Sensor cable loss limits - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 34

Site analysis checklist - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -35

Cable requirements - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -36

Equipment requirements - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -36

3 Installing FiberPatrol - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -37

FiberPatrol installation overview - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -37

Laser light safety - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -37

Optical fiber safety - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -38

Fiber optic cable handling - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -38

FiberPatrol standard sensor cable performance specifications - - - - - - - - - - - - - - - - - - - - - 38

Additional cable requirements - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 38

Cable loss limits (maximum attenuation) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 39

Cable handling recommendations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 39

Illustrated installation requirements - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 39

FiberPatrol sensor cable and below ground bypasses - - - - - - - - - - - - - - - - - - - - - - - - - - - 43

FiberPatrol installation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -43

Attaching the sensor cable - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -44

Attaching the sensor cable at protected gates - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 45

Masonry walls and buildings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -46

Sensor cable verification and test - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -47

Continuity test - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 47

OTDR test - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 47

Control equipment installation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -47

FiberPatrol splices - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -48

4 Maintenance - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -49

Recommended maintenance - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -49

System Diagnostics - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -51

System Status Reporting - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -51

Remote Systems - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 51

Local Systems - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 52

Common Scenarios - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 52

Troubleshooting procedures - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -53

Facility and Equipment Access - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -53

System Inspection - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 53

Sensor unit hardware check - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 53

FiberPatrol Site Planning & Installation Guide Page 5

Sensor unit interface check - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 53

FiberPatrol software check - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 54

Cable connections check - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 54

Sensor unit reboot - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 55

Malfunction Reporting - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 55

5 IDS software environment - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -57

FiberPatrol Sensor Unit - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 57

Operator access level - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 58

Supervisor access level - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 58

Installer access level - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 58

6 Configuration & calibration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -59

Initial configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 59

Safe Start - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 60

FiberPatrol sensor cable configurations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 63

System configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 64

Global Setup - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 65

Troubleshooting dialog - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 66

Calibration setup - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 66

Optical location identification - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 66

Location calibration - the tap test - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 67

Tap test setup - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 67

Location Calibration for Loop configurations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 68

Calibrating the Set Start for Sensor 1 and the Set End for Sensor 2 (Loop configurations) - - 68

Calibrating the Set Start for Sensor 2 and Set End for Sensor 1 (Loop configurations) - - - - - 69

Calibrating the Sensor 2 Offset (Loop configurations) - - - - - - - - - - - - - - - - - - - - - - - - - - - - 70

Calibration setup for Split configurations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 71

Calibrating the Sensor Scales and Offsets - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 71

Verify the sensor start point - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 71

Location calibration for Split configurations: - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 72

Calibration setup for Line configurations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 72

Calibrating the Set Start location (Line configurations) - - - - - - - - - - - - - - - - - - - - - - - - - - - 72

Calibrating the Set End position (Line configurations) - - - - - - - - - - - - - - - - - - - - - - - - - - - - 73

Calibrating the Offsets and Scales (Line configurations) - - - - - - - - - - - - - - - - - - - - - - - - - - 73

Locating the site features and zone boundaries - - - - - - - - - - - - - - - - - - - - - - - - - 74

Zone boundary and site feature identification - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 76

At the start point of sensing cable - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 76

At splice locations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 77

At sensitivity loops (corners, tension posts, heavy gauge posts) - - - - - - - - - - - - - - - - - - - - 77

At gate locations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 77

At bypass locations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 78

At locations of non-linear cable deployment - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 78

At Zone boundary locations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 79

Creating the site map - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 80

Acquiring the site map image - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 80

Map image navigation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 80

Creating the perimeter - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 83

Select the Area of Interest (AOI) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 85

Importing Configuration Files into the FiberPatrol IDS software - - - - - - - - - - - - - - - - - 86

Page 6 FiberPatrol Site Planning & Installation Guide

Defining the Zone Boundaries (Zone Definitions) - - - - - - - - - - - - - - - - - - - - - - - - - -88

Remote Interface/Alarm output setup - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -89

Setting Alarm Detection Parameters - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -90

Intrusion simulation tests - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -91

Simulated cut intrusion tests - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 92

Simulated climb intrusion tests - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 92

Setting the full cable Sensitivity Thresholds - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -92

Setting zone specific Sensitivity Thresholds - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -93

Fine-tuning detection parameters - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -94

Environment Compensation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 94

Temporal Compensation: - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 94

Spatial Compensation: - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 95

Motion Rejection – Parallel Settings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 95

Motion Rejection – Perpendicular Settings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 96

Save Raw Data - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 98

Load Raw Data - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 98

Frequency Display - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 98

Additional installer level settings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -99

Configuration File Safety Backup - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -100

7 Operator’s functions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 101

FiberPatrol Definitions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -101

Auto-start routine - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -102

Manual Windows login - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -102

Starting the FiberPatrol software - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -102

FP1150 User access levels - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -102

FiberPatrol Operator Control Panel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -103

Status Panel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -103

System Status - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -104

Alarm Status field - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -104

Alarm Location field - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -104

Menu bar - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -105

System menu - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -105

Help menu - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -105

Alarms Sub-Panel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -105

Alarm List - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -105

Alarm Attributes - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -105

Map Display - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -105

Clear Alarm button - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -106

Operator actions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -106

Alarm Dialog details - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -106

Alarm History Sub-Panel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -107

8 Supervisor’s functions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 109

Log Sub-Panel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -109

The Signal sub-panel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -110

Disturbance signal display graphs - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -111

Disturbance History display - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -111

Supervisor menus - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -111

System menu - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -112

FiberPatrol Site Planning & Installation Guide Page 7

Manage menu - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 112

Configure menu - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 112

Service menu - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 113

Supervisor functions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -114

Zone Definition - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 114

Zone Masking (Access) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 115

Password maintenance - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 116

Alarm Auto Clearing Settings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 116

Remote Interface - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 117

a System component list - - - - - - - - - - - - - - - - - - - - - - - - 119

b Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - 121

c Location/calibration table - - - - - - - - - - - - - - - - - - - - - - 123

d Remote Alarm Output - - - - - - - - - - - - - - - - - - - - - - - - 125

Network Manager Alarm reporting Setup - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -125

Communication content - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 125

Communication timing - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 126

Page 8 FiberPatrol Site Planning & Installation Guide

FiberPatrol Site Planning & Installation Guide Page 9

1 System description

Principles of operation

The FiberPatrol FP1150 fence-mounted perimeter intrusion detection system detects and locates

intruders using fiber optic technology. FiberPatrol senses and locates minute vibrations in the

fence caused by climbing, cutting, lifting, or otherwise disturbing the fence fabric. A fiber optic

sensor cable is attached to the perimeter fence. The sensor unit (SU) transmits laser light into two

single-mode fibers in the sensor cable. The SU picks up the back-scatter reflections caused by

fence motion or vibrations in the fence fabric and processes the data to determine the magnitude

and location of each disturbance. The sensor unit triggers an alarm when a disturbance meets the

criteria for a valid intrusion.

The sensor cable is a communication-grade single-mode fiber optic cable intended for outdoor

installation. The cable includes two dedicated sensing fibers. Depending on the particular fiber

optic cable used, at least 10 dark fibers are available for other perimeter applications (e.g., CCTV,

data communication, etc.). The sensor cable is easily attached to the fence with cable ties.

However, all fiber connections require fusion splicing to telecom industry standards. The sensor

unit fiber optic connections use FC/APC type connectors.

The FiberPatrol system includes Windows-based configuration and alarm display software, which

is used to setup and calibrate the system. The configuration software can also serve as an

operator interface to the system for alarm monitoring. The configuration software enables sensor

calibration, detection parameter adjustments, system configuration settings and alarm processing.

FiberPatrol can operate as a standalone sensor, which communicates alarm conditions via

optional relay output modules. A PC-based security management system, such as the Network

Manager’s Alarm Integration Module, or StarNet 2, can serve as the primary operator interface for

a FiberPatrol system. FiberPatrol can also report alarms to 3rd party security management

systems (SMS) via the Network Manager Service. The security management system monitors the

FiberPatrol sensor, and can report alarms to an operator on a graphic site-map.

FiberPatrol sensor system details

• passive, fiber optic, fence mounted outdoor perimeter intrusion detection system

• uses standard outdoor rated telecommunication grade single-mode fiber optic cables

• additional dark fibers available for auxiliary perimeter device communications

• models available for single pass coverage for fences up to 3 m (10 ft.) high

• no power required for outdoor components

• outdoor components unaffected by lightning, EMI, or electrical transients

• outdoor rated splice enclosures for fiber termination and access to fibers at drop points

Page 10 FiberPatrol Site Planning & Installation Guide

• indoor components are rack-mountable in a standard EIA 19 in. equipment rack:

• sensor unit - 4RU component transmits laser light into two dedicated fibers and receives

and isolates back-scatter signals via the integral start module, analyzes the received

signal, locates disturbances, triggers alarms, monitors system status, includes Windows

operating system, FiberPatrol system software, configuration software and Network

Manager software

• fiber connection module - 1RU panel for connecting the 2 fiber sensors (S1 and S2) from

the sensor unit to the lead cable in the equipment room, includes one 12-splice tray for

making the required fusion splices, a dual end module or a second splice tray can be

added, if required

• rack-mount LCD keyboard/monitor/mouse combo - 1 RU panel provides control,

maintenance, calibration and configuration access to the FiberPatrol processor

FP1150 configurations

There are three distinct configurations for the FP1150 Series sensor:

• Loop configurations in which the two sensors run in opposite directions in one fiber optic

cable.

• Split configurations in which the two sensors run in opposite directions, in two fiber optic

cables.

• Line configurations in which both sensors run in the same direction in one fiber optic cable.

The loop configuration provides single cable cut immunity whereby detection will continue over the

full length of the perimeter in the event of a single cut in the sensor cable. In the split configuration,

the two sensors work independently to provide twice the linear length of protection as compared to

the loop configuration. However, a cut cable ends detection beyond the point of the cut. In the line

configuration, the two sensors run in the same direction in the sensor cable and work in tandem for

alarm detection. With the line configuration, a cut cable ends detection beyond the point of the cut.

Figure 1 FiberPatrol block diagram - fully closed loop redundant configuration

with dual end modules

1 fiber optic sensor cable

non-detecting lead cables

2 fiber optic

equipment room

perimeter

fiber connection module

sensor unit

keyboard/monitor/mouse

security

system

management
