EDIFIER TWS NBQ EDF201005 User manual
True Wireless Earbuds with Active Noise Cancellation
TWS NBQ
www.edifier.com
Function button
Ear tips Charging cableStorage bag
Note:
•Please use the "R" button for functional operations, as the "L" button is only an
decorative part.
•There are different size of ear tips attached in the package, please select the
suitable ones to wear.
•Images are for illustrative purposes only and may differ from the actual product.
EN · Product description and accessories
● Charge the earbuds
Warning: The rechargeable batteries that provide power for this product must be
disposed properly for recycling. Do not dispose of batteries in fire to prevent an explosion.
■ User guide
•Place the earbuds in the case and close
the case for charging.
● Charge the charging case
Input: 5V 60mA(earbuds)
5V 1A(charging case)
•
Connect the included charging cable to
the case for charging.
•
Indicator steady lit = charging
Indicator off = fully charged
● Battery level indicator on the
charging case
•
Open/close the case or single press the
button to show the case’s battery level;
if indicator flashes three times: full battery level
if indicator flashes twice: medium battery level
if indicator flashes once: low battery level
•Battery level indicator (next to the charging
port)
EDIFIER TWS NBQ
● Pairing
● Power on when the case
is opened.
● Power o when the case
is closed.
•Bluetooth pairing: white and
green lights flash rapidly.
•After pairing is successful, the
green light will flash slowly.
•Place the earbuds in the case, and press
and hold the "R" button for around
3 seconds to enter Bluetooth pairing.
•Search for and connect to "EDIFIER TWS
NBQ".
Green light is steady lit once
R
L
● Functional operation
●
Interconnection of the leftand right earbuds/clear pairing records
Place the earbuds in the case, and double click the "R" button (white light flashing
rapidly) to clear pairing records and enter TWS pairing mode of the left and right
earbuds. When successful, white and green lights will flash rapidly.
Pause/play:
double click the right earbud
Accept/end a call:
double click the left or right earbud
Mode switch:
double click the left earbud
Next track:
triple click the right earbud
Game mode:
triple click the left earbud
Note:
•Mode switch: noise cancellation mode(effective when both earbuds are used),
ambient sound mode, and normal mode.
Whenchargingthe charging case, the indicator is o.
•
Please ensure the charging case is correctly connected with power source.
No sound
•
Check if the earbuds are operating.
•
Check if the earbuds volume are at an appropriate level.
•
Check if the earbuds are correctly connected with mobile phone.
•
Check if the earbuds are operating within a normal working range.
The call quality of the earbuds are not good.
•
Check if mobile phone is in an area with strong signal.
•
Please ensure the earbuds are within effective distance (10m) and no
obstacle between the earbuds and mobile phone.
When playing music, cannot control pause/play/next track via the
earbuds.
•
Please ensure the paired device support
AVRCP (Audio Video Remote
Control Profile) profile.
■ FAQs
•Do not use a fast charger to charge the product to avoid affecting service
live of the battery.
•If it is not used for long periods of time, please charge the product with
lithium battery every three months.
•Keep the product away from humid places to avoid affecting internal
circuit. Do not use the product during intense exercise or with much
sweat to prevent sweat from dropping into the product to make
damage.
•Do not put the product in places exposed to sun or with high
temperature. High temperature will shorten service life of electronic
components, damage battery and make plastic components deformed.
•Do not put the product in cold places to avoid damaging internal
circuit board.
•Do not dismantle the product. Non-professional personnel may
damage the product.
•Do not drop, strongly vibrate, strike the product with hard object to
avoid damaging internal circuit.
•Do not use drastic chemicals or cleaner to clean the product.
•Do not use sharp objects to scratch product surface to avoid
damaging shell and affecting facade.
■ Maintenance
Model: EDF201005
Edifier International Limited
P.O. Box 6264
General Post Office
Hong Kong
www.edifier.com
2021 Edifier International Limited. All rights reserved.
Printed in China
NOTICE:
For the need of technical improvement and system upgrade, information
contained herein may be subject to change from time to time without
prior notice.
Products of EDIFIER will be customized for different applications. Pictures
and illustrations shown on this manual may be slightly different from
actual product. If any difference is found, the actual product prevails.
Bouton de fonction
Oreillettes antibruit Câble de rechargeÉtui de rangement
FR · Description du produit et accessoires
Remarque:
•Veuillez utiliser le bouton «R» pour l’utilisation de l’appareil, car le bouton «L» fait
seulement office de décoration.
•Différentes tailles d’embout sont disponibles dans l’emballage, veuillez choisir la
plus appropriée.
•
Les images utilisées servent de référence uniquement, et peuvent ne
pas correspondre au produit.
● Charger les écouteurs
Avertissement: La batterie rechargeable qui alimente ce produit doit être éliminée
de façon appropriée pour le recyclage. Ne pas jeter une batterie au feu sous risque
d'explosion.
■ Instructions d’utilisation
•Placez les écouteurs dans l’étui-chargeur
et fermez-le pour les charger.
● Charger le boîtier de charge
Entrée: 5V 60mA(écouteur)
5V 1A(étui-chargeur)
•
Branchez le câble de charge inclus à
l’étui-chargeur pour charger.
•
Les indicateur restent illuminés = en charge
Les indicateur éteint = complètement chargé
● Achage du niveau de batterie
du boîtier de charge
•
Ouvrez/Fermez l’étui-chargeur ou appuyez
une fois sur le bouton pour consulter le
niveau de charge de l’étui-chargeur;
Si le voyant clignote trois fois: batterie
pleinement chargée
Si le voyant clignote deux fois: batterie
moyennement chargée
Si le voyant clignote une fois: batterie
presque déchargée
•
Indicateur du niveau de batterie (à côté du
port de charge)
