Cambridge Audio Azur 840W User manual

Power Output

200 watts per channel into 8 ohms

300 watts per channel into 4 ohms

500 watts mono into 8 ohms in bridged mode.

Audio Inputs:

1 pairs Gold Plated RCA stereo phono inputs

1 pair XLR balanced inputs

Audio Outputs

1 pairs Gold Plated RCA stereo phono outputs

1 pair XLR balanced outputs

Other Connections

12v trigger in/out, control bus in/out, IR emitter in.

A & B speaker premium gold plated binding posts

Damping factor

>300

Frequency Response:

10Hz –50kHz +/- 1dB

Signal to Noise ratio

83 db

THD(unweighted):

<0.0015% @ 1kHz

Max. Power Consumption:

1200 Watts (Standby: 12 Watts)

Dimensions (W x D x H):

430 x 385 x 145mm

Weight:

21.8kg/48.2 lbs

Azur 840W Class XD Power Amplifier

The 840W is a high-end power amplifier that has been

designed by the same team behind the 840A and uses an

evolution of Cambridge Audio’s hugely innovative Class

XD™ technology for a highly detailed naturally musical

performance. The second generation Class XD is now

complemented by a new output stage carefully adjusted to

integrate with this novel technology, along with revised

balanced input connections for lower distortion and noise

circuits. Each channel uses 2 pairs of very high output

transistors to ensure that the 840W can drive even the

most demanding load At the core of the 840W’s strength

is a patent pending, Class XD (crossover displacement)

technology This unique design gives pure Class A operation

at low levels, moving smoothly into an enhanced version of

Class B at higher levels.

The 840W delivers an impressive 200 watts per channel in

stereo mode, and can be bridged to output a massive 500

watt mono output. Also included is the latest development of

Cambridge Audio’s proprietary CAP5 protection system.

CAP5 (Cambridge Audio Protection 5) is an innovative and

intelligent protection system. It constantly monitors the

amplifier, without degrading signal purity, ensuring ultimate

reliability and high performance from this mighty amplifier.

Azur 840w Features

Cambridge Audio, Gallery Court, Hankey Place, London SE1 4BB

©2007 Cambridge Audio Ltd. Issued August 2007

Cambridge Audio’s policy is one of improvement.

Designs and specifications are therefore subject to

change without notice

XXXXXXX Specifications

Azur 840W Class XD Power Amplifier
