Boston Acoustics Pro50 SE User manual

Specifications Pro50 SE

Nominal Size 51/4"

RMS Power Handling 125 watts

Peak Power Handling 250 watts

Nominal Impedance 3 ohms

Frequency Response 60Hz–22kHz (± 3dB)

Sensitivity 90dB (1watt @ 1meter)

High Performance 51/4-inch Component Speaker System

# Description Quantity

1 Pro50 SE Woofer 2

2 Type-M1 1" Alloy Dome Tweeter 2

3 Pro50 SE Woofer Crossover 2

4 Pro50 SE Tweeter Crossover 2

5 Tweeter Grille 2

6 Tweeter Axis-Mount 2

7 Tweeter Flush-Mount 2

8 Tweeter Angle-Mount (top) 2

9 Tweeter Angle-Mount (bottom) 2

10 Adapter Plate 2

11 Woofer Gasket 2

not shown Woofer Hardware Package 1

12 Boston Hex Tool 1

13 Woofer Grille 2

14 Small Gold Terminal 2

15 Large Gold Terminal 2

16 Crossover Bridge 2

not shown Tweeter Hardware Pack 2

17 Axis-Mount Screws 4

18 Spring Clips 4

19 Compact Gold Terminals 4

20 Axis-Mount Stand-Off 2

21 3/8" Pan Head Screw 2

22 1" Pan Head Screw 2

not shown 1/2" Pan Head Screw 2

23 11/8" Socket Button Head Screw 16

24 11/2" Hex Nut 2

25 1/2" Self-Tapping Screw 4

26 1" Self-Tapping Screw 4

27 3/32" Hex Bit 1

2 1/4"

57mm

6 7/16"

163mm

1 7/16"

36mm

1 5/8"

40mm

6 1/2"

165mm

3 11/16"

94mm

2 1/16"

52mm

1 1/2"

38mm

51mm

1 3/4"

45mm

3/4"

19mm

1 1/8"

27mm

Boston Acoustics, Inc. 300 Jubilee Drive, Peabody, MA 01960 USA T: 978.538.5000 F: 978.538.5100 W: bostonacoustics.com

Boston, Boston Acoustics, and the Boston Acoustics logo are registered trademarks of Boston Acoustics, Inc.

Specifications are subject to change without notice.

5¼-inch (135mm) Adapter

Crossover - Single Input

Signal Bridge Crossover - Daisy Chain Crossover - All Connected Crossover - Connection

Crossover - Bi-Wire / Bi-Amp

3 4 3 4 3 4 3 4

3 4 3 4 3 4 4

Tweeter

Woofer

Axis-Mount Tweeter Attenuation Axis / Component Configuration

Key on Back Page

Angle-Mount Tweeter Installation

Flush-Mount
