Behringer Tube Ultragain MIC100 User manual

Version 1.0 January 2003

Technical Specifications

ENGLISH

TUBE ULTRAGAIN MIC100

MII

ICC

C100100

100100

100

TUBE ULTRAGAIN

Vacuum Tube Preamplifier with Limiter

VHigh-endtubemic/linepreamplifierforstudio,liveandharddiskrecordingapplications

VHand-selected12AX7vacuumtubewithUTCtechnologyforexceptionalwarmthandlowestnoise

VTheultimate sound-enhancing tool for virtually any sound source

VPerfectlycomplements studio-grade condenser mics

VUsageasahigh-end DI-box ensures outstanding signal integrity

VEliminates the “dull” sound of standard digital recorders and sound cards

VDynamiclimiter effectively protects your equipment from overload

VPhase reverse switch, +48 V phantom power and 20 dB pad for utmost flexibility

VBalancedinputsand ouputs on 1/4" TRS and gold-plated XLR connectors

VHighlyaccurate8-segmentLED level meter

VExtremelywide-rangeinput gain and output level adjustment

SPECIFICATIONS

XLR input

Connector Balanced/unbalanced

Type Transformerless,DC-decoupledinput

Impedance approx. 2 kΩ

Max.input level +7 dBu / 20 dB with pad

1/4" TRS input

Connector Balanced/unbalanced

Type Transformerless,DC-decoupledinput

Impedance approx. 1 MΩ

Max.input level +16 dBu / 20 dB with pad

Audiooutputs

Connectors XLRand 1/4"TRS connectorbalanced/unbalanced

Type Transformerless,DC-decoupledoutput

Impedance approx.700 Ωbalanced / approx. 350 Ωunbalanced

Max.output level approx. +26 dBu @ 100 kΩ

Systemspecifications

Frequencyresponse Mic input <10 Hz - 43 kHz (+/-3 dB)

Line input <10 Hz - 40 kHz (+/-3 dB)

Functioncontrols

Gain variable(+26 to +60 dB)

Output variable(-oo to +10 dB)

Functionswitches

20 dB pad Level attenuation(20dB)

+48 V Activatesthe phantompower

Phasereverse Phasereverse(180°)

Limiter Limits the output signal

Indicators

Inputlevel 8-segment LED meter: -24, -18, -12, -6, 0, +6, +12, clip

Power-LED Indicatesoperation

Power supply

Mainsvoltages USA/Canada 120 V~, 60 Hz, PSU

U.K./Australia 240 V~, 50 Hz, PSU

Europe 230 V~, 50 Hz, PSU

Japan 100 V~, 50 - 60 Hz, PSU

Physical

Dimensions (H x W x D) approx. 2 1/2" (64 mm) x 5 1/4" (135 mm) x 5 1/4" (135 mm)

Weight(without power supply) approx. 0.5 kg (1.1 lbs)

BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be

made from time to time to existing products without prior notice. Specifications and appearance may differ from those listed or

shown.

The information contained in this manual is subject to change without notice. No part of this manual may be reproduced or

transmitted in any form or by any means, electronic or mechanical, including photocopying and recording of any kind, for any

purpose, without the express written permission of BEHRINGER Spezielle Studiotechnik GmbH.

BEHRINGERandULTRAGAINareregistered trademarks.ALLRIGHTSRESERVED.

BEHRINGERSpezielleStudiotechnikGmbH, Hanns-Martin-Schleyer-Str.36-38, 47877 Willich-MünchheideII, Germany

Tel. +49 (0) 21 54 / 92 06-0, Fax +49 (0) 21 54 / 92 06-30
