Badger Basket Round Doll Crib 01905 Installation guide

1.0/0705

MODEL #: 01905

NAME: Round Doll Crib

TOOLS NEEDED: Phillips Screwdriver, Hammer

PARTS INCLUDED:

(A) 1 - Top Ring

(B) 4 - Leg Posts

(D) 15 - Dowels*

(E) 8 - Short Screws (not shown)

(F) 1 - Bottom Ring

(G) 4 - Caster Wheels

(H) 1 - Canopy Pole with Curve/Bend

(I) 1 - Metal Canopy Frame

(J) 1 - Fabric Skirt

(K) 1 - Fabric Sheet

(L) 1 - Mattress Pad

(M) 1 - Fabric Canopy

* IMPORTANT: 4 of the dowels have holes in both ends,

11 have no holes or a small hole in only one end

ASSEMBLY INSTRUCTIONS

Adult Assembly Required.

Save these instructions for future use.

This item is a toy for dolls only.

For children ages three (3) years and older.

Visit us online at www.badgerbasket.com

Toll-Free Customer Service: 1-800-236-1310 (Monday through Thursday 7:30 AM to 4:30 PM CST)

[email protected]

PLANT AND GENERAL OFFICE: PO Box 227, Edgar, WI 54426-0227 715-352-2311 Fax: 715-352-3163

CORPORATE OFFICE: 111 Lions Dr., Suite 220, Barrington, IL 60010

Page 1 of 3

BEFORE

YOU

BEGIN

ASSEMBLY:

Ensure that all

the parts and

hardware listed above are

included. If anything is

missing, please do not return

the product to the store. Call

or e-mail us for assistance.

1.0/0705Page 2 of 3

PICTURE 3

PICTURE 2

STEP 1: See PICTURE 1. Attach the FOUR LEG

POSTS (B) to their designated spots on the TOP RING

(A) using the FOUR LONG SCREWS (C).

Attach the FOUR DOWELS WITH TWO HOLES (D)

using FOUR SHORT SCREWS (E). The positions of

these four dowels may vary from shown in Picture 1.

STEP 2: See PICTURE 2. Turn the crib upside down.

Insert the FOUR LEG POSTS (B) through the large

holes on the BOTTOM RING (F) and slide the bottom

ring down until it rests on the DOWELS WITH TWO

HOLES (D).

Be sure screw and dowel holes on the bottom ring are

in the right place, and the white side of the bottom

platform is facing down (white side will face up when

the crib is in the upright position).

Starting at any dowel, work your way around the ring

and alternately screw down the FOUR DOWELS

WITH TWO HOLES (D) using FOUR SHORT

SCREWS (E) and insert the remaining ELEVEN

DOWELS (D) sandwiched between the top and bottom

rings.

There is one hole for the canopy pole that you will

leave open.

STEP 3: See PICTURE 3. Turn the crib right side up.

Insert the FOUR CASTER WHEELS (G) into the

holes on the bottom of the LEG POSTS (B). Grasp

each leg and gently but firmly press each wheel against

the floor to snap it into place.

PICTURE 1

1.0/0705

STEP4: See PICTURES 4A and 4B. Insert the CANOPY POLE (H) through the hole on the TOP RING (A) and push it

down until it rests in the hole on the BOTTOM RING (F). Insert the two free ends of the METAL CANOPY FRAME (I)

into the top of the CANOPY POLE (H). You may need to gently tap on the canopy frame with a hammer so that the ends

are pushed down into the pole as far as possible (see PICTURE 4B).

Starting by the canopy pole, wrap the FABRIC SKIRT (J) around the BOTTOM RING (F) pressing the grip tape together.

When you get back to where you started, press the grip tape on the two ends of the skirt together. Put the FABRIC SHEET

(K) on the MATTRESS PAD (L) and place the sheet and pad into the crib.

STEP5: See PICTURE 5. Position the FABRIC CANOPY (M) over the METAL CANOPY FRAME (I). Secure the grip

tape tabs on the fabric canopy around the metal frame.Adjust the canopy so it drapes around the crib.

Your ROUND DOLLCRIB is now ready to enjoy! This beautiful item is suitable

for children from three years old and up. Please make sure children know that this

furniture is for dolls and stuffed animals only. It is NEVER to be used with real

infants or with pets. Children should NEVER attempt to sit orstand on the crib.

Page 3 of 3

PICTURE 4A

PICTURE 4B

K, L

PICTURE 5

Care instructions: Wipe crib parts and vinyl pad clean with a damp cloth

and mild detergent as needed. Fabric is poly/cotton. For longevity of the product we

recommendhandwashingthe bedding;however itcan bemachine washedon gentle

and air dried or tumble dried on low or no heat. Iron on the

lowestsetting forpoly/cotton.
