AEG L9WS99OKO User manual

USER

MANUAL

EN User Manual

Washer Dryer

L9WS99ÖKO

CONTENTS

1. SAFETY INFORMATION...........................................................................................3

2. SAFETY INSTRUCTIONS.......................................................................................... 5

3. INSTALLATION......................................................................................................... 7

4. PRODUCT DESCRIPTION...................................................................................... 14

5. CONTROL PANEL...................................................................................................16

6. PROGRAMMES ...................................................................................................... 20

7. CONSUMPTION VALUES.......................................................................................24

8. SETTINGS................................................................................................................ 25

9. OPTIONS................................................................................................................. 26

10. BEFORE FIRST USE...............................................................................................27

11. DAILY USE - WASHING ONLY.............................................................................28

12. DAILY USE - DRYING ONLY................................................................................ 32

13. DAILY USE - WASHING & DRYING.....................................................................33

14. HINTS AND TIPS...................................................................................................34

15. CARE AND CLEANING........................................................................................ 36

16. TROUBLESHOOTING...........................................................................................42

17. TECHNICAL DATA............................................................................................... 46

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you

impeccable performance for many years, with innovative technologies that help

make life simpler features you might not find on ordinary appliances. Please

spend a few minutes reading to get the very best from it.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.aeg.com/webselfservice

www.registeraeg.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.aeg.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the

following data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

www.aeg.com

1. SAFETY INFORMATION

Before the installation and use of the appliance,

carefully read the supplied instructions. The

manufacturer is not responsible for any injuries or

damages that are the result of incorrect installation or

usage. Always keep the instructions in a safe and

accessible location for future reference.

1.1 Children and vulnerable people safety

WARNING!

Risk of suffocation, injury or permanent

disability.

•This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning the use of the appliance in a

safe way and understand the hazards involved.

•Do not let children play with the appliance.

•Children aged 3 years and under must be kept away

from this appliance when it is in operation at all times.

•Keep all packaging away from children and dispose of

it appropriately.

•Keep detergents away from children.

•Keep children and pets away from the appliance door

when it is open.

•If the appliance has a child safety device, this should

be activated.

•Children shall not carry out cleaning and user

maintenance of the appliance without supervision.

1.2 General Safety

•Do not change the specification of this appliance.

•The appliance shall be installed as a freestanding

product or below the kitchen worktop if space

margins permit.

ENGLISH 3

•Do not install the appliance behind a lockable door, a

sliding door or a door with a hinge on the opposite

side, that would prevent the appliance door from

being fully opened.

•Connect the mains plug to the mains socket only at

the end of the installation process. Make sure that the

mains plug is accessible after installation.

•The ventilation opening in the base (if applicable)

must not be covered by a carpet, mat, or any floor

covering.

•Ensure good air ventilation in the located room to

avoid the backflow of unwanted gases into the room

from appliances burning gas or other fuels, including

open fires.

•Exhaust air must not be discharged into a flue which is

used for exhausting fumes from any appliances

burning gas or other fuels.

•The operating water pressure at the water entry point

from the outlet connection must be between 0.5 bar

(0.05 MPa) and 8 bar (0.8 MPa).

•Do not exceed the maximum load of 9 kg (refer to the

"Programme chart" chapter).

•The appliance must be connected to the water mains

using the new supplied hose sets, or other new hose

sets supplied by the Authorised Service Centre.

•Old hose sets must not be reused.

•If the mains power supply cable is damaged, it must

be replaced by the manufacturer, its Authorised

Service Centre or similarly qualified persons to avoid

an electrical hazard.

•Wipe away lint or packaging debris that has

accumulated around the appliance.

•Do not run the appliance without filters. Clean the lint

filter before or after each use.

•Items that have been soiled with substances such as

vegetable or mineral oil, acetone, alcohol, petrol,

kerosene, spot removers, turpentine, waxes and wax

removers should be washed separately with an extra

www.aeg.com

amount of detergent before being dried in the washer

dryer.

•Do not use the appliance if items have been soiled

with industrial chemicals.

•Do not dry unwashed items in the wash dryer.

•Items such as foam rubber (latex foam), shower caps,

waterproof textiles, and rubber backed articles and

clothes, or pillows fitted with foam rubber pads should

not be dried in the washer dryer.

•Fabric softeners, or similar products, should only be

used as specified by the product manufacturer’s

instructions.

•Remove all objects from items that could be a source

of fire ignition such as lighters or matches.

•Never stop the washer dryer before the end of the

drying cycle unless all items are quickly removed and

separated so that residual heat can dissipate.

•The final part of the washer dryer cycle takes place

without heat (cool down cycle) to ensure that items

reach a temperature that will not cause damage to

them.

•Do not use high pressure water sprays and/or steam

to clean the appliance.

•Clean the appliance with a moist cloth. Use only

neutral detergents. Do not use abrasive products,

abrasive cleaning pads, solvents or metal objects.

•Before any maintenance operation, deactivate the

appliance and disconnect the mains plug from the

socket.

2. SAFETY INSTRUCTIONS

2.1 Installation

• Follow the installation instruction

supplied with the appliance.

• Do not install or use the appliance

where the temperature can be less

than 5°C or higher than 35 °C.

• Always keep the appliance vertical

when being moved.

• To make sure the compressor works

properly, wait 6 hours after the

installation before using the

appliance.

• Make sure that there is air circulation

between the appliance and the floor.

• Remove all the packaging and the

transit bolts.

ENGLISH 5

• The floor area where the appliance is

to be installed must be flat, stable,

heat resistant and clean.

• Keep the transit bolts in a safe place.

If the appliance is to be moved in

future they must be reattached to lock

the drum to prevent internal damage.

• Always take care when moving the

appliance as it is heavy. Always use

safety gloves and enclosed footwear.

• Do not install or use a damaged

appliance.

• Do not install the appliance where the

appliance door cannot be fully

opened.

• Adjust the feet to have the necessary

space between the appliance and the

flooring.

• When the appliance is in its

permanent position, check that it is

fully level with the aid of a spirit level.

If it is not, adjust the feet accordingly.

2.2 Electrical Connection

WARNING!

Risk of fire and electrical

shock.

• The appliance must be earthed.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

• Do not touch the mains cable or the

mains plug with wet hands.

• This appliance complies with the

E.E.C. Directives.

2.3 Water Connection

• Do not cause damage to the water

hoses.

• Before connection to new pipes,

pipes not used for a long time, where

repair work has been carried out or

new devices fitted (water meters,

etc.), let the water flow until it is clean

and clear.

• Ensure that there are no visible water

leaks during and after the first use of

the appliance.

2.4 Use

WARNING!

Risk of injury, electrical

shock, fire, burns or damage

to the appliance.

• This appliance is for household use

only.

• Do not put flammable products or

items that are wet with flammable

products in, near or on the appliance.

• Do not touch the glass door while a

programme is in operation. The glass

can get hot.

• Do not dry damaged (torn, frayed)

items that contain padding or fillings.

• If laundry has been washed with a

stain remover, carry out an additional

rinse cycle before starting a drying

cycle.

• Make sure that all metal objects are

removed from the laundry.

• Only dry fabrics that are suitable to

dry in the washer dryer. Follow the

cleaning instruction on the item label.

• Plastic items are not heat resistant.

– If a detergent ball is used, remove

it before starting a drying

programme.

– Do not use a detergent ball if

setting a non-stop programme.

WARNING!

Risk of injury or damage to

the appliance.

• Do not sit or stand on the open door.

• Do not dry dripping wet clothes in the

appliance.

2.5 Compressor

WARNING!

Risk of damage to the

appliance.

• The compressor and its system in the

washer-dryer is filled with the special

agent which is free from fluoro-

chlorohydrocarbons. This system must

stay tight. The damage of the system

can cause a leakage.

www.aeg.com

2.6 Disposal

• Disconnect the appliance from the

mains electrical and water supplies.

• Cut off the mains electrical cable

close to the appliance and dispose of

it.

• Remove the door catch to prevent

children or pets from becoming

trapped in the drum.

• Dispose of the appliance in

accordance with local requirements

for the disposal of Waste Electrical

and Electronic Equipment (WEEE).

3. INSTALLATION

WARNING!

Refer to Safety chapters.

3.1 Unpacking

WARNING!

As you will put down the appliance on the rear side, wait about 6 hours

before you use it. This time is necessary to enable the compressor to

work properly.

WARNING!

Remove all the packaging and the transit bolts before installing the

appliance.

Use the gloves.

• Remove the external film. If necessary,

use a cutter

• Remove the cardboard top.

• Remove the polystyrene packaging

materials.

ENGLISH 7

• Remove the internal film.

• Open the door.

• Remove the polystyrene piece from

the door seal and all the items from

the drum.

• Put one of the polystyrene packaging

elements on the floor behind the

appliance.

• Carefully put down the appliance with

the rear side on it.

• Make sure not to damage the hoses.

• Remove the polystyrene protection

from the bottom.

www.aeg.com8

• Fully clean and dry the bottom of the

appliance.

• Do not use alcohol, solvents or

chemical products.

Make sure to identify the different sizes

and the positions of the sound barriers.

Refer to the illustration:

•A(FRONT) = Front of the appliance

•B(BACK) = Rear of the appliance

• Remove the adhesive strip from the

silent barriers.

• Attach the four barriers to bottom of

the appliance.

• Refer to the illustration. Make sure

that the barriers are securely attached.

Attach the sound barriers

at a room temperature.

• Pull up the appliance in vertical

position.

ENGLISH 9

• Remove the power supply cable and

the drain hose from the hose holders.

It is possible to see water

flowing from the drain

hose. This is due to the

testing with water of the

appliances in factory.

• Remove the three bolts.

• Use the key supplied with the

appliance.

• Pull out the plastic spacers.

• Put the plastic caps in the holes.

• You can find these caps in the user

manual bag.

We recommend that you keep the packaging and the transit bolts for any

movement of the appliance.

3.2 Fixing plate kit

(4055171146)

Available from your authorised dealer.

If you install the appliance on a plinth,

secure the appliance in the fixing plates.

Read carefully the instructions supplied

with the accessory.

www.aeg.com10

Table of contents

Popular Washer Dryer manuals by other brands

Whirlpool

Whirlpool WFC8090GX Use and care guide and installation instructions

Whirlpool

Whirlpool LTE5243DQ6 User instructions

Bosch

Bosch XQG100-WDU285H00W User manual and installation instructions

montpellier

montpellier MWD7512S Installation and operating instructions

LG FHD0905 T Series owner's manual

Midea

Midea MF200D85B owner's manual

Maytag

Maytag MGT3800XW installation instructions

Siemens

Siemens WD15G440TR Instruction manual and installation instructions

Equator

Equator Clothes Processor EZ1500 owner's manual

Splendide

Splendide WDC7100XCP Specifications

John Lewis

John Lewis JLWD 1408 instruction manual

Ariston

Ariston A1200WD Instruction booklet

Whirlpool

Whirlpool YLTE5243DQ5 installation instructions

Whirlpool

Whirlpool WFCR 75230 Health & safety, use & care and installation guide

ATT

ATT Hammer Jet v1 operating manual

Electrolux

Electrolux EWW8024P5WB user manual

GE GTD42EASJWH owner's manual

LG F2721HVRB owner's manual
